Schneider Electric AP8853X678 rack accessory

Rack Pdu 2G. Metered. Zerou. 32A. 230V. ClIPsal 56 Series As/Nz Input Plug. (36) C13 & (6) C19 Outlets

Description

Rack PDU 2G, Metered, ZeroU, 32A, 230V, Clipsal 56 series AS/NZ input plug, (36) C13 & (6) C19 outlets

APC Metered Rack Power Distribution Units (PDUs) provide active metering to enable energy optimization and circuit protection. User-defined alarm thresholds mitigate risk with real-time local and remote alerts to warn of potential circuit overloads. Metered Rack PDUs provide power utilization data to allow Data Center Managers to make informed decisions on load balancing and right sizing IT environments to lower total cost of ownership. Metered Rack PDUs include real power monitoring, a temperature/humidity sensor port, locking IEC receptacles, and ultra low profile circuit breakers. Users can access and configure Metered Rack PDUs through secure Web, SNMP, or Telnet Interfaces which are complimented by APC Centralized Management platforms using StruxureWare software suite.
Main Input Voltage 200 V 208 V 230 V
PDU type Metered
Main Output Voltage 230 V
Number of rack unit 0U
Cable length 3.00 m
Number of cables 1
Provided equipment- Installation guide, Rack mounting brackets, Serial configuration cable
Permissible voltage 220…240 V
Max line current 32 A
Input current limits 32 A
Network frequency 50/60 Hz
Number of input connectors 1 clipsal 32A 56P332
Number of power socket outlets- 36 IEC 60320 C13, 6 IEC 60320 C19
Ambient air temperature for operation -5…45 °C
Relative humidity 5…95 %
Operating altitude 0...10000 ft
Ambient air temperature for storage -25…65 °C
Storage Relative Humidity 5…95 %
Storage altitude 0.00…15240.00 m
Product certifications VDE

Mounting mode- Not rack mountable

Specifications

Features
Rack capacity	0U
Product colour	Black
Operating temperature (T-T)	-5 - 45 °C
Storage temperature (T-T)	-25 - 65 °C
Operating relative humidity (H-H)	5 - 95%
Power
AC input frequency	50 - 60 Hz
Input voltage	200 - 208 V
Output voltage	230 V
Weight & dimensions
Package width	107 mm
Package depth	162 mm
Package height	2000 mm
Package weight	8.56 kg
Width	56 mm
Weight	6.93 kg
Height	1791 mm
Depth	44 mm
Packaging data
Package width	107 mm
Package depth	162 mm
Package height	2000 mm
Package weight	8.56 kg
Operational conditions
Operating temperature (T-T)	-5 - 45 °C
Storage temperature (T-T)	-25 - 65 °C
Technical details
Warranty period	2 year(s)
