Collection: Storage Drive Docking Stations

NVMe M.2 + SATA HDD and SSD Dual Bay Docking Station USB 3.2 Gen 2 10Gbps Offline Clone

Key Features

• One M.2 slot for NVMe M.2 SSD
• One SATA slot for 3.5" or 2.5" SATA HDD/SSD
• USB 3.2 Gen2 interface support up to 10Gbps data transfer rate
• Support multi-LUN (logical unit number), each slot has a separate drive letter
• Access data from NVMe M.2 and SATA slots simultaneously
• Support offline clone, standalone duplicating without host computer
• Clone direction switch allows two-way clone between NVMe M.2 and SATA drives
• Supports USAP for faster data transfer speed and maximum performance
• Supports TRIM command for improved data writing to extend SSD life
• Plug and play, no additional driver software required

Description

SD570 is an all-in-one USB docking station that supports both NVMe M.2 and SATA drives. The M.2 slot supports NVMe SSD, and SATA slot support 3.5" or 2.5" SATA HDD/SSD. USB 3.2 Gen 2 interface support up to 10Gbps data transfer rate and can be easily attached to computer USB-C port. SD570 is designed for easy and fast access to NVMe M.2 and SATA HDD/SSD. With multi-LUN (logical unit number) support, it will show two separate drive letters for NVMe M.2 and SATA slots, so you can access data from NVMe M.2 and SATA drive simultaneously, and copy files from one drive to another easily. Save and tidy your desktop space, SD570 is a perfect all-in-one device for NVMe M.2 and SATA drives, so you don’t need separate devices to read different types of SSD or HDD. In addition, SATA M.2 and mSATA SSDs also can be supported with an optional SATA to M.2 and mSATA adapter. It also can be used as a standalone duplicator dock when not connecting USB to a computer. It has a clone direction switch that allows two-way clone between NVMe M.2 and SATA drives. Ideal for data backup and migration, this docking station provides a simple and fast solution for backup data, batch processing data, formatting, file transfers, data recovery, and more.

Specifications

Hard drive
Storage media type	HDD, SSD
Storage drive interface	Serial ATA III
Storage drive sizes supported	2.5,3.5,M.2
Number of storage drives supported	2
Ports & interfaces
Host interface	USB 3.2 Gen 2 (3.1 Gen 2) Type-C
Technical details
Maximum data transfer rate	10 Gbit/s
Product colour	Black
Plug and Play	Yes
TRIM support	Yes
Features
Maximum data transfer rate	10 Gbit/s
LED indicators	Activity, Power
Product colour	Black
Plug and Play	Yes
TRIM support	Yes
Power
Output voltage	12 V
Output current	3 A
Weight & dimensions
Width	122 mm
Depth	181 mm
Height	34 mm
Indication
LED indicators	Activity, Power
Software
Mac compatibility	Yes
Windows operating systems supported	Windows 10, Windows 11, Windows 7, Windows 8, Windows 8.1
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks, Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey
Ethernet LAN features
LED indicators	Activity, Power
Packaging content
AC adapter included	Yes
Cables included	USB Type-C to USB Type-C
Manual	Yes

USB3.0, SATA 3, 2.5", 3.5", 480Mbps

Key Features

• Designed for direct insertion of one 2.5 inch or 3.5 inch SATA HDD/SSD
• USB 3.0 SuperSpeed Interface, transfer rates up to 5Gbps
• Backwards-Compatible with USB 2.0, transfer rates up to 480Mbps
• Touch Control ON/OFF switch
• LED light indicates Power and Activity status
• Hot-swappable, plug and play, no drivers needed
• Support UASP (USB Attached SCSI) for Windows 8 and above, Mac OS 10.8 and above
• Compatible Operating Systems: Windows XP and above (32/64-bit), Mac OS 10.4 and above, Linux

Description

Simplecom SD326 USB 3.0 to SATA Hard Drive Docking Station offers swappable access to 2.5" and 3.5" SATA HDD/SSD without having to mount the hard drive or install it in an enclosure. It provides a simple, fast, and cost effective solution for data recovery, drive imaging, or any environment that requires fast access to 3.5" or 2.5" drives. The super speed USB 3.0 interface supports transfer rate up to 5Gbps.

Specifications

Hard drive
Storage media type	HDD, SSD
Storage drive interface	Serial ATA, Serial ATA II, Serial ATA III
Storage drive sizes supported	2.5,3.5,5.25"
Number of storage drives supported	1
Ports & interfaces
Host interface	USB 3.2 Gen 1 (3.1 Gen 1) Type-B
USB 3.2 Gen 1 (3.1 Gen 1) ports quantity	1
DC-in jack	Yes
Technical details
Maximum data transfer rate	5 Gbit/s
Product colour	Black
Plug and Play	Yes
Hot-swap	Yes
Features
Maximum data transfer rate	5 Gbit/s
LED indicators	Activity, Power
Product colour	Black
Plug and Play	Yes
Hot-swap	Yes
Cooling
Built-in fan	No
Power
AC input voltage	100 - 240 V
Output voltage	12 V
Output current	2 A
Indication
LED indicators	Activity, Power
Software
Mac compatibility	Yes
Windows operating systems supported	Windows 10,Windows 11,Windows 8,Windows 8.1
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks, Mac OS X 11.0 Big Sur
Ethernet LAN features
LED indicators	Activity, Power
Packaging content
AC adapter included	Yes
Cables included	USB
Manual	Yes

Dual Bay USB 3.0 Docking Station for 2.5" and 3.5" SATA Drive

Key Features

• Designed for direct insertion of two 2.5 inch or 3.5 inch SATA HDD/SSD
• USB 3.0 SuperSpeed Interface, transfer rates up to 5Gbps
• Backwards-Compatible with USB 2.0, transfer rates up to 480Mbps
• Low profile design with SATA drive bay lid, which is also the HDD holder when opened
• LED light indicates Power and Activity status
• Hot-swappable, plug and play, no drivers needed
• Support UASP (USB Attached SCSI Protocol)
• Support offline clone, easy installation, computer-independent duplicating/cloning without computer support, high efficiency
• Dimensions: 133mm x 125mm x 50mm
• Compatible with Windows XP and above (32/64-bit), Mac OS 10.4 and above

Description

The Simplecom SD312 is a low profile SATA Docking Station, which supports direct insertion of two 2.5" or 3.5" SATA drives. It provides a simple, fast, and cost effective solution for data recovery, drive imaging, and testing centers, or any environment that requires fast access to uninstalled/archived SATA drives. With USB 3.0 interface, you can take advantage of super speed data transfer rate up to 5Gbps. Connecting to your computer through an available USB 3.0 port on desktop or laptop, ready for Plug and Play/Hot Swap and no additional driver is needed. With offline cloning technology, SD312 can copy your files from one disk to another without a computer connected.

Specifications

Hard drive
Storage media type	HDD, SSD
Storage drive interface	Serial ATA
Storage drive sizes supported	2.5,3.5"
Number of storage drives supported	2
Ports & interfaces
Host interface	USB 3.2 Gen 1 (3.1 Gen 1) Type-B
DC-in jack	Yes
Technical details
UASP support	Yes
Maximum data transfer rate	5 Gbit/s
Product colour	Black
Material	Acrylonitrile butadiene styrene (ABS)
Plug and Play	Yes
Hot-swap	Yes
On/off switch	Yes
Features
UASP support	Yes
Maximum data transfer rate	5 Gbit/s
LED indicators	Activity, Power
Product colour	Black
Material	Acrylonitrile butadiene styrene (ABS)
Plug and Play	Yes
Hot-swap	Yes
On/off switch	Yes
Weight & dimensions
Width	133 mm
Depth	125 mm
Height	50 mm
Indication
LED indicators	Activity, Power
Software
Mac compatibility	Yes
Windows operating systems supported	Yes
Mac operating systems supported	Yes
Ethernet LAN features
LED indicators	Activity, Power
Packaging content
AC adapter included	Yes
Cables included	USB
Manual	Yes

Dual Bay USB 3.0 Aluminium Docking Station for 2.5" and 3.5" SATA HDD

Key Features

• Designed for direct insertion of two 2.5 inch or 3.5 inch SATA HDD/SSD
• USB 3.0 SuperSpeed Interface, transfer rates up to 5Gbps
• Backwards-Compatible with USB 2.0, transfer rates up to 480Mbps
• Solid aluminium casing with glossy ABS top panel, elegant and stylish
• LED light indicates Power and Activity status
• Hot-swappable, plug and play, no drivers needed
• Support offline clone, easy installation, computer-independent duplicating/cloning without computer support, high efficiency
• Reliable and high watts DC power supply, so that a stable energy supply is guaranteed
• Compatible Operating Systems: Windows XP and above (32/64-bit), Mac OS 10.10 and Above, Linux

Description

Simplecom SD322 SATA Docking Station supports the direct insertion of two 2.5" or 3.5" SATA Hard Drives. It provides a simple, fast, and cost effective solution for data recovery, drive imaging, and testing centers, or any environment that requires fast access to uninstalled/archived drives. Plus, now you can take advantage of the super speed USB 3.0 to quickly transfer files up to 5 Gbps. Connect any 2.5"/3.5" Serial ATA (SATA) Hard Drive to your computer through an available USB 3.0 port on your desktop or laptop. With completely offline cloning technology, Simplecom SD322 can copy your files from one disk to another without computer support. Ready for Plug and Play/Hot Swap and no Additional Driver is needed.

Specifications

Hard drive
Storage media type	HDD, SSD
Storage drive interface	Serial ATA
Storage drive sizes supported	2.5,3.5"
Number of storage drives supported	2
Ports & interfaces
Host interface	USB 3.2 Gen 1 (3.1 Gen 1) Type-B
DC-in jack	Yes
Technical details
Maximum data transfer rate	5 Gbit/s
Product colour	Black
Material	Acrylonitrile butadiene styrene (ABS), Aluminium
Plug and Play	Yes
Hot-swap	Yes
On/off switch	Yes
Features
Maximum data transfer rate	5 Gbit/s
LED indicators	Activity, Power
Product colour	Black
Material	Acrylonitrile butadiene styrene (ABS), Aluminium
Plug and Play	Yes
Hot-swap	Yes
On/off switch	Yes
Indication
LED indicators	Activity, Power
Software
Mac compatibility	Yes
Windows operating systems supported	Yes
Mac operating systems supported	Yes
Linux operating systems supported	Yes
Ethernet LAN features
LED indicators	Activity, Power
Packaging content
Package type	Box
AC adapter included	Yes
Cables included	USB
Manual	Yes
Packaging data
Package type	Box
