Collection: PC/Workstation Barebones

Intel Atom x7211E (6M Cache, up to 3.20 GHz), 1 x SODIMM DDR5, Intel Wi-Fi 6E AX210, Bluetooth 5.2, Dual 2.5G Ethernet, 90W, 884 g

Key Features

• Kits and boards offer the perfect combination of performance, connectivity, and reliability in a fanless, dust-resistant ruggedized chassis
• Can withstand 0° to 50°C external ambient operating temperatures on select kits
• Built to survive environments most PCs can't
• Versatile mounting options to put compute where it's needed
• Qualified for 24/7 sustained operation1

Description

Reliable performance in unreliable conditions

Make amazing experiences possible
Unlock unparalleled performance, connectivity, and reliability with ASUS NUC 13 Rugged kits and boards. Expertly crafted in a fanless, dust-resistant ruggedized chassis, these devices showcase the perfect synergy of power and durability. Featuring the Intel® Processor N50 and Intel® Atom® processors, ASUS NUC 13 Rugged devices are tailor-made for applications that demand resilience against dust exposure, shocks, and vibration. Select kits are engineered to endure extended external ambient temperatures (0-50°C on tall chassis), ensuring unwavering performance even in the most demanding conditions. Elevate your computing experience with the ideal blend of strength and sophistication.

Specifications

Processor
Built-in processor	Yes
Processor model	x7211E
Processor boost frequency	3.2 GHz
Processor family	Intel Atom®
Processor manufacturer	Intel
Processor cache	6 MB
Memory
Memory slots type	SO-DIMM
Number of memory slots	1
Supported memory types	DDR5-SDRAM
Supported memory clock speeds	4800 MHz
Maximum internal memory	16 GB
Video
Graphics card family	Intel
On-board graphics card	Yes
Storage
Storage drive sizes supported	M.2
Storage drive interface	M.2
SSD form factor	M.2
Graphics
Graphics card family	Intel
On-board graphics card	Yes
On-board graphics card model	Intel® UHD Graphics
Audio
Built-in speaker(s)	No
Network
Wi-Fi standards	Wi-Fi 6E (802.11ax)
Ethernet LAN	Yes
Wi-Fi	Yes
Bluetooth version	5.2
Bluetooth	Yes
Top Wi-Fi standard	Wi-Fi 6E (802.11ax)
WLAN controller model	Intel Wi-Fi 6E AX210
Ports & interfaces
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	2
VGA (D-Sub) ports quantity	0
USB 2.0 ports quantity	2
HDMI version	2.1
HDMI ports quantity	2
Ethernet LAN (RJ-45) ports	2
DC-in jack	Yes
Design
Product type	Mini PC barebone
On/off switch	Yes
Product colour	Black
Cable lock slot type	Kensington
Cable lock slot	Yes
Performance
Windows operating systems supported	Windows 11
Operating system installed	No
Colour
Product colour	Black
Technical details
Cable lock slot type	Kensington
Cable lock slot	Yes
Software
Windows operating systems supported	Windows 11
Operating system installed	No
Management features
On/off switch	Yes
Power
Power supply	90 W
Weight & dimensions
Width	174 mm
Depth	108 mm
Height	35.8 mm
Weight	884 g

Intel N150 (6M Cache, up to 3.60 GHz), Intel Graphics, WiFi 6e, no OS, 1 x SO-DIMM, Realtek Ethernet Controller RTL8125BG-CG, 2.5G

Key Features

• Energy-efficient: Ideal for lightweight office productivity and embedded applications
• Triple display support: Boosting Office Workflow Efficiency
• Easy access design: Ease of upgrades, lower maintenance costs and reduced downtime
• Multiple high-speed connection options: Experience heightened productivity with a diverse array of high-speed connectivity options, ensuring accelerated and stable data transfers
• Abundant I/O: High flexibility to meet various workflow and scenarios
• Compact size: Easy to deploy for small offices, retail settings, educational institutions

Description

Power efficient Mini PC powered by Intel® Core™ N-Series processor, featuring triple 4K display supports and easy access design, perfect for education and office tasks

Efficient Performance. Smart Savings.
ASUS NUC 14 Essential is the next-generation mini PC that takes performance, portability, and versatility to greater heights. Powered by the latest energy-efficient Intel® Core™ N-series processors and equipped with diverse connectivity options, this sleek, compact device is built to boost productivity and makes light work of diverse applications.

Specifications

Motherboard
Processor socket	BGA 1264
Number of processors supported	1
Processor
Built-in processor	Yes
Processor model	N150
Processor boost frequency	3.6 GHz
Processor threads	4
Processor socket	BGA 1264
Processor cores	4
Number of processors supported	1
Processor manufacturer	Intel
Processor cache	6 MB
Memory
Memory slots type	SO-DIMM
Number of memory slots	1
Supported memory types	DDR5-SDRAM
Supported memory clock speeds	4800 MHz
Maximum internal memory	16 GB
Internal memory installed	No
Video
Graphics card family	Intel
On-board graphics card	Yes
Storage
Supported storage drive types	SSD
Storage drive sizes supported	M.2
Storage drive interface	M.2, Serial ATA
Number of storage drives supported	2
Maximum storage capacity	2 TB
SSD form factor	M.2
NVMe	Yes
Storage drives installed	No
Graphics
Graphics card family	Intel
On-board graphics card	Yes
On-board graphics card model	Intel® Graphics
Discrete graphics card model	Not available
Performance
Processor socket	BGA 1264
Number of processors supported	1
Operating system installed	No
Audio
Built-in speaker(s)	No
Network
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax)
Ethernet LAN	Yes
Wi-Fi	Yes
LAN controller	Dragon RTL8125BG
Bluetooth version	5.3
Bluetooth	Yes
Copper ethernet cabling technology	2.5GBASE-T
Top Wi-Fi standard	Wi-Fi 6E (802.11ax)
WLAN controller model	Intel Wi-Fi 6E AX211
Ports & interfaces
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	4
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	2
DisplayPort version	1.4
VGA (D-Sub) ports quantity	0
USB 2.0 ports quantity	1
Headphone outputs	1
HDMI version	2.1
HDMI ports quantity	1
Ethernet LAN (RJ-45) ports	1
DisplayPorts quantity	1
DC-in jack	Yes
Design
VESA mounting	Yes
Product type	Mini PC barebone
On/off switch	Yes
Product colour	Black
Cable lock slot type	Kensington
Cable lock slot	Yes
Colour
Product colour	Black
Technical details
Cable lock slot type	Kensington
Cable lock slot	Yes
Packaging data
Power cord included	No
Software
Operating system installed	No
Management features
On/off switch	Yes
Power
AC adapter output voltage	19 V
AC adapter output current	3.42 A
Power supply type	External AC adapter
Power supply	65 W
Weight & dimensions
Width	135 mm
Depth	115 mm
Height	36 mm
Weight	480 g
Packaging content
Power cord included	No

NUC 13 Rugged, Intel Atom x7425E (TDP12W), 1 x SO-DIMM DDR5 4800 MT/s memory 8GB~16GB

Key Features

• Kits and boards offer the perfect combination of performance, connectivity, and reliability in a fanless, dust-resistant ruggedized chassis
• Can withstand 0° to 50°C external ambient operating temperatures on select kits
• Built to survive environments most PCs can't
• Versatile mounting options to put compute where it's needed
• Qualified for 24/7 sustained operation

Description

Make amazing experiences possible
Unlock unparalleled performance, connectivity, and reliability with ASUS NUC 13 Rugged kits and boards. Expertly crafted in a fanless, dust-resistant ruggedized chassis, these devices showcase the perfect synergy of power and durability. Featuring the Intel® Processor N50 and Intel® Atom® processors, ASUS NUC 13 Rugged devices are tailor-made for applications that demand resilience against dust exposure, shocks, and vibration. Select kits are engineered to endure extended external ambient temperatures (0-50°C on tall chassis), ensuring unwavering performance even in the most demanding conditions. Elevate your computing experience with the ideal blend of strength and sophistication.

Powerful performance in a small, durable footprint
Like all ASUS NUCs, the ASUS NUC 13 Rugged is a versatile platform for edge solutions with a small form factor, platform longevity, and I/O expandability. To unlock new possibilities for ASUS partners and their customers, the ASUS NUC 13 Rugged incorporates a rugged, fanless, heat-and dust-resistant design with flexible mounting options.This latest evolution of the NUC can be deployed in more places and service more challenging use cases with standout performance, self-healing*, and display capabilities.

Specifications

Processor
Thermal Design Power (TDP)	12 W
Built-in processor	Yes
Processor model	x7425E
Processor boost frequency	3.4 GHz
Processor family	Intel Atom®
Processor cores	4
Processor manufacturer	Intel
Processor cache	6 MB
Memory
Memory slots type	SO-DIMM
Number of memory slots	1
Supported memory types	DDR5-SDRAM
Maximum internal memory	16 GB
Video
Graphics card family	Intel
On-board graphics card	Yes
Storage
Supported storage drive types	SSD
Storage drive sizes supported	M.2
SSD form factor	M.2
Graphics
Graphics card family	Intel
On-board graphics card	Yes
On-board graphics card model	Intel® UHD Graphics
Audio
Built-in speaker(s)	No
Network
Wi-Fi standards	Wi-Fi 6E (802.11ax)
Ethernet LAN	Yes
Wi-Fi	Yes
LAN controller	Intel I226-V
Bluetooth version	5.3
Bluetooth	Yes
Top Wi-Fi standard	Wi-Fi 6E (802.11ax)
WLAN controller model	Intel Wi-Fi 6E AX210
Ports & interfaces
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	2
VGA (D-Sub) ports quantity	0
USB 2.0 ports quantity	2
HDMI version	2.1
HDMI ports quantity	2
Ethernet LAN (RJ-45) ports	2
DC-in jack	Yes
Design
Product type	Mini PC barebone
On/off switch	Yes
Product colour	Black
Colour
Product colour	Black
Management features
On/off switch	Yes
Power
AC adapter output voltage	20 V
AC adapter output current	4.5 A
Power supply type	External AC adapter
Power supply	90 W
Weight & dimensions
Width	174 mm
Depth	108 mm
Height	35.8 mm
Weight	1.04 kg

Intel Core i5-1335U, 2 x SO-DIMM DDR5-5200 max 64GB, 1 x 2.5" SSD/HDD, 2 x M.2-2280, Intel UHD Graphics, 2 x LAN (1 x 2.5Gbit, 1 x 1Gbit), 90W

Key Features

• Fanless 1.3L-PC supports 24/7 operating
• Dual LAN (1x 2.5Gbit , 1x 1Gbit) , 1x COM (RS232) , VESA
• HDMI, Display Port and VGA

Description

Fanless Slim PC with integrated ULV processor in industrial design
The DS50U-series is a fanless slim PC with a robust 1.3-litre metal chassis and exceptional connectivity. It supports two digital video outputs for UHD/4K displays and one traditional D-Sub/VGA connector. The built-in Intel Gen 12/13 processor provides ample performance for playback of 2160p/60 videos. Installation of components goes straight forward, as there is plenty of interior space for two DDR5 memory modules, one 2.5" drive and two M.2-2280 SSD cards.

Optionally, an 4G/5G module can be fitted in the second M.2 slot using the optional WWN04 accessory. Thanks to its passive cooling, the system is virtually maintenance-free and is approved for 24/7 nonstop operation. It is big on performance, yet extremely energy-efficient. The Shuttle XPC slim Barebone DS50U5 series is an ideal platform for professional applications such as digital signage, POS, Kiosk, Thin Client, Office PC and Multimedia.

Specifications

Motherboard
Number of processors supported	1
Processor
Thermal Design Power (TDP)	15 W
Built-in processor	Yes
Processor model	i5-1335U
Processor boost frequency	4.6 GHz
Processor threads	12
Processor family	Intel® Core™ i5
Processor cores	10
Number of processors supported	1
Processor manufacturer	Intel
ECC supported by processor	No
Processor cache	12 MB
Performance cores	2
Efficient cores	8
Performance-core boost frequency	4.6 GHz
Efficient-core boost frequency	3.4 GHz
Processor generation	13th gen Intel® Core™ i5
Memory
Memory voltage	1.1 V
Memory slots type	SO-DIMM
Number of memory slots	2
Supported memory types	DDR5-SDRAM
Supported memory clock speeds	5200 MHz
Memory channels	Dual-channel
Maximum internal memory	64 GB
Internal memory installed	No
Video
Graphics card family	Intel
On-board graphics card	Yes
Storage
Supported storage drive types	HDD & SSD
Storage drive sizes supported	2.5,M.2
Storage drive interface	PCI Express, Serial ATA III
Number of storage drives supported	3
NVMe	Yes
Storage drives installed	No
Graphics
Graphics card family	Intel
On-board graphics card	Yes
On-board graphics card model	Intel® UHD Graphics
Audio
Built-in speaker(s)	No
Audio chip	RealTek ALC888S
Network
Ethernet LAN	Yes
Wi-Fi	No
LAN controller	Intel® I219, Intel I226-LM
Ports & interfaces
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	2
DisplayPort version	1.4
VGA (D-Sub) ports quantity	1
USB 2.0 ports quantity	2
Serial ports quantity	1
Microphone in	Yes
Headphone outputs	1
HDMI version	2.0b
HDMI ports quantity	1
Ethernet LAN (RJ-45) ports	2
DisplayPorts quantity	1
DC-in jack	Yes
Design
VESA mounting	Yes
Product type	Mini PC barebone
Housing material	Steel
Panel mounting interface	75 x 75,100 x 100 mm
On/off switch	Yes
LED indicators	HDD, Power
Cooling type	Passive
Product colour	Black
Chassis type	1.3L sized PC
Cable lock slot type	Kensington
Cable lock slot	Yes
Performance
Windows operating systems supported	Windows 10, Windows 11
Linux operating systems supported	Yes
Trusted Platform Module (TPM) version	2.0
Trusted Platform Module (TPM)	Yes
Operating system installed	No
Number of processors supported	1
BIOS type	UEFI AMI
Audio chip	RealTek ALC888S
Harmonized System (HS) code	84733080
Colour
Product colour	Black
Technical details
Panel mounting interface	75 x 75,100 x 100 mm
Trusted Platform Module (TPM) version	2.0
Trusted Platform Module (TPM)	Yes
Quick start guide	Yes
Cooling type	Passive
Chassis type	1.3L sized PC
Cable lock slot type	Kensington
Cable lock slot	Yes
BIOS type	UEFI AMI
Harmonized System (HS) code	84733080
Sustainability compliance	Yes
Sustainability certificates	ENERGY STAR, ErP
Compliance certificates	BSMI, CB, CE, Federal Communications Commission (FCC), RCM, RoHS, VCCI, cTUVus
Packaging data
Power cord included	Yes
AC adapter included	Yes
Package weight	2.3 kg
Indication
LED indicators	HDD, Power
Software
Windows operating systems supported	Windows 10, Windows 11
Linux operating systems supported	Yes
Operating system installed	No
Management features
On/off switch	Yes
Logistics data
Harmonized System (HS) code	84733080
Sustainability
Sustainability compliance	Yes
Sustainability certificates	ENERGY STAR, ErP
Power
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
AC adapter output voltage	19 V
AC adapter output current	1.6 A
Power supply type	External AC adapter
Power supply	90 W
Number of power supply units	1
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90%
Weight & dimensions
Width	200 mm
Depth	165 mm
Height	39.5 mm
Weight	1.6 kg
Package weight	2.3 kg
Packaging content
Quick start guide	Yes
Power cord included	Yes
AC adapter included	Yes
Other features
Chassis type	1.3L sized PC

Intel Celeron 7305, 2 x SO-DIMM DDR5-5200 max 64GB, 1 x 2.5" SSD/HDD, 2 x M.2-2280, Intel UHD Graphics, 2 x LAN (1 x 2.5Gbit, 1 x 1Gbit), 90W

Key Features

• Fanless 1.3L-PC supports 24/7 operating
• Dual LAN (1x 2.5Gbit , 1x 1Gbit) , 1x COM (RS232) , VESA
• HDMI, Display Port and VGA

Description

Fanless Slim PC with integrated ULV processor in industrial design
The DS50U-series is a fanless slim PC with a robust 1.3-litre metal chassis and exceptional connectivity. It supports two digital video outputs for UHD/4K displays and one traditional D-Sub/VGA connector. The built-in Intel Gen 12/13 processor provides ample performance for playback of 2160p/60 videos. Installation of components goes straight forward, as there is plenty of interior space for two DDR5 memory modules, one 2.5" drive and two M.2-2280 SSD cards.

Optionally, an 4G/5G module can be fitted in the second M.2 slot using the optional WWN04 accessory. Thanks to its passive cooling, the system is virtually maintenance-free and is approved for 24/7 nonstop operation. It is big on performance, yet extremely energy-efficient. The Shuttle XPC slim Barebone DS50U series is an ideal platform for professional applications such as digital signage, POS, Kiosk, Thin Client, Office PC and Multimedia.

Specifications

Motherboard
Number of processors supported	1
Processor
Built-in processor	Yes
Processor model	7305
Processor threads	5
Processor family	Intel® Celeron®
Processor cores	5
Number of processors supported	1
Processor manufacturer	Intel
ECC supported by processor	No
Performance cores	1
Efficient cores	4
Memory
Memory voltage	1.1 V
Memory slots type	SO-DIMM
Number of memory slots	2
Supported memory types	DDR5-SDRAM
Supported memory clock speeds	5200 MHz
Memory channels	Dual-channel
Maximum internal memory	64 GB
Video
Graphics card family	Intel
On-board graphics card	Yes
Storage
Supported storage drive types	HDD & SSD
Storage drive sizes supported	2.5,M.2
Storage drive interface	PCI Express, Serial ATA III
Number of storage drives supported	3
NVMe	Yes
Graphics
Graphics card family	Intel
On-board graphics card	Yes
On-board graphics card model	Intel® UHD Graphics
Audio
Built-in speaker(s)	No
Audio chip	RealTek ALC888S
Network
Ethernet LAN	Yes
Wi-Fi	No
LAN controller	Intel® I219, Intel I226-LM
Ports & interfaces
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	2
DisplayPort version	1.4
VGA (D-Sub) ports quantity	1
USB 2.0 ports quantity	2
Serial ports quantity	1
Microphone in	Yes
Headphone outputs	1
HDMI version	2.0b
HDMI ports quantity	1
Ethernet LAN (RJ-45) ports	2
DisplayPorts quantity	1
DC-in jack	Yes
Design
VESA mounting	Yes
Product type	Mini PC barebone
Housing material	Steel
Panel mounting interface	75 x 75,100 x 100 mm
On/off switch	Yes
LED indicators	HDD, Power
Cooling type	Passive
Product colour	Black
Chassis type	1.3L sized PC
Cable lock slot type	Kensington
Cable lock slot	Yes
Performance
Windows operating systems supported	Windows 10, Windows 11
Linux operating systems supported	Yes
Trusted Platform Module (TPM) version	2.0
Trusted Platform Module (TPM)	Yes
Operating system installed	No
Number of processors supported	1
BIOS type	UEFI AMI
Audio chip	RealTek ALC888S
Harmonized System (HS) code	84733080
Colour
Product colour	Black
Technical details
Panel mounting interface	75 x 75,100 x 100 mm
Trusted Platform Module (TPM) version	2.0
Trusted Platform Module (TPM)	Yes
Quick start guide	Yes
Cooling type	Passive
Chassis type	1.3L sized PC
Cable lock slot type	Kensington
Cable lock slot	Yes
BIOS type	UEFI AMI
Harmonized System (HS) code	84733080
Sustainability compliance	Yes
Sustainability certificates	ENERGY STAR, ErP
Compliance certificates	BSMI, CB, CE, Federal Communications Commission (FCC), RCM, RoHS, VCCI, cTUVus
Packaging data
Power cord included	Yes
AC adapter included	Yes
Package weight	2.3 kg
Indication
LED indicators	HDD, Power
Software
Windows operating systems supported	Windows 10, Windows 11
Linux operating systems supported	Yes
Operating system installed	No
Management features
On/off switch	Yes
Logistics data
Harmonized System (HS) code	84733080
Sustainability
Sustainability compliance	Yes
Sustainability certificates	ENERGY STAR, ErP
Power
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
AC adapter output voltage	19 V
AC adapter output current	1.6 A
Power supply type	External AC adapter
Power supply	90 W
Number of power supply units	1
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90%
Weight & dimensions
Width	200 mm
Depth	165 mm
Height	39.5 mm
Weight	1.6 kg
Package weight	2.3 kg
Packaging content
Quick start guide	Yes
Power cord included	Yes
AC adapter included	Yes
Other features
Chassis type	1.3L sized PC

ASUS NUC 14 Essential RNUC14MNK2500000, Mini PC barebone, DDR5-SDRAM, M.2, Ethernet LAN, 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E..., 65 W

Description

ASUS NUC 14 Essential RNUC14MNK2500000. Product type: Mini PC barebone. Supported memory types: DDR5-SDRAM, Number of memory slots: 1, Maximum internal memory: 16 GB. Supported storage drive types: SSD, Storage drive interface: M.2, Maximum storage capacity: 2 TB. Ethernet LAN (RJ-45) ports: 1. Wi-Fi standards: 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E..., Bluetooth version: 5.3. Power supply: 65 W

Specifications

Processor
Built-in processor	Yes
Processor model	N250
Processor boost frequency	3.8 GHz
Processor threads	4
Processor cores	4
Processor manufacturer	Intel
Processor cache	6 MB
Memory
Memory slots type	SO-DIMM
Number of memory slots	1
Supported memory types	DDR5-SDRAM
Supported memory clock speeds	4800 MHz
Maximum internal memory	16 GB
Internal memory installed	No
Video
Graphics card family	Intel
On-board graphics card	Yes
Storage
Supported storage drive types	SSD
Storage drive sizes supported	M.2
Storage drive interface	M.2
Number of storage drives supported	1
Maximum storage capacity	2 TB
SSD form factor	M.2
Storage drives installed	No
Graphics
Graphics card family	Intel
On-board graphics card	Yes
On-board graphics card model	Intel® Graphics
Audio
Built-in speaker(s)	No
Network
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax)
Ethernet LAN	Yes
Wi-Fi	Yes
LAN controller	Dragon RTL8125BG
Bluetooth version	5.3
Bluetooth	Yes
Copper ethernet cabling technology	2.5GBASE-T
Top Wi-Fi standard	Wi-Fi 6E (802.11ax)
WLAN controller model	Intel Wi-Fi 6E AX211
Ports & interfaces
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	4
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	2
DisplayPort version	1.4
VGA (D-Sub) ports quantity	0
USB 2.0 ports quantity	1
Headphone outputs	1
HDMI version	2.1
HDMI ports quantity	1
Ethernet LAN (RJ-45) ports	1
DisplayPorts quantity	1
DC-in jack	Yes
Design
VESA mounting	Yes
Product type	Mini PC barebone
On/off switch	Yes
Product colour	Black
Cable lock slot type	Kensington
Cable lock slot	Yes
Performance
Operating system installed	No
Colour
Product colour	Black
Technical details
Cable lock slot type	Kensington
Cable lock slot	Yes
Software
Operating system installed	No
Management features
On/off switch	Yes
Power
AC adapter output voltage	19 V
AC adapter output current	3.42 A
Power supply type	External AC adapter
Power supply	65 W
Weight & dimensions
Width	135 mm
Depth	115 mm
Height	36 mm
Weight	480 g

LGA1700, Intel H610, 2 x SO-DIMM DDR5-5600 max. 96GB, PCI-Express Gen. 3.0 X4, Serial-ATA III, 1G LAN + 2.5G LAN, 120W

Description

The Shuttle XPC slim Barebone DH610V2 with H610 chipset houses the performance of Intel's 12th/13th/14th generation Core desktop processors (codenamed Alder Lake-S and Raptor Lake-S [Refresh]) for socket LGA1700 in a compact 1.3-litre format. The DH610V2 allows for three Ultra HD displays to be operated at the same time via 1x HDMI and 2x DisplayPort. It also offers Dual Intel LAN (one supports 2.5G speed), eight USB ports and two COM ports. The slim metal chassis comes with a VESA mount included, provides versatile connectivity and reliable operation in environments with ambient temperatures of up to 50 °C. This platform is targeted at professional applications such as Digital Signage, POS, POI, gambling machines, office, healthcare and industry.

Specifications

Motherboard
Processor socket	LGA 1700
Number of processors supported	1
Motherboard chipset	Intel H610
Processor
Built-in processor	No
Processor socket	LGA 1700
Number of processors supported	1
Motherboard chipset	Intel H610
Memory
Memory voltage	1.1 V
Memory slots type	SO-DIMM
Number of memory slots	2
Supported memory types	DDR5-SDRAM
Supported memory clock speeds	5600 MHz
Memory channels	Dual-channel
Maximum internal memory	96 GB
ECC	No
Non-ECC	Yes
Internal memory installed	No
Video
On-board graphics card	Yes
Storage
Supported storage drive types	HDD & SSD
Storage drive sizes supported	2.5,M.2
NVMe	Yes
Storage drives installed	No
Graphics
On-board graphics card	Yes
Audio
Built-in speaker(s)	No
Audio chip	Realtek ALC888S
Network
Ethernet LAN	Yes
Wi-Fi	No
LAN controller	Intel I226, Intel I219V
Ports & interfaces
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	1
DisplayPort version	1.4
USB 2.0 ports quantity	4
Serial ports quantity	2
Microphone in	Yes
Headphone outputs	1
HDMI version	2.0b
HDMI ports quantity	1
Ethernet LAN (RJ-45) ports	2
DisplayPorts quantity	2
DC-in jack	Yes
Design
VESA mounting	Yes
Product type	Mini PC barebone
Housing material	Metal
Panel mounting interface	75 x 75,100 x 100 mm
On/off switch	Yes
LED indicators	Power, HDD
Cooling type	Active
Product colour	Black
Chassis type	1.35L sized PC
Cable lock slot type	Kensington
Cable lock slot	Yes
Performance
Windows operating systems supported	Windows 10, Windows 11
Linux operating systems supported	Yes
Trusted Platform Module (TPM) version	2.0
Trusted Platform Module (TPM)	Yes
Processor socket	LGA 1700
Number of processors supported	1
Motherboard chipset	Intel H610
BIOS type	AMI
Audio chip	Realtek ALC888S
Colour
Product colour	Black
Technical details
Panel mounting interface	75 x 75,100 x 100 mm
Trusted Platform Module (TPM) version	2.0
Trusted Platform Module (TPM)	Yes
Quick start guide	Yes
Cooling type	Active
Chassis type	1.35L sized PC
Cable lock slot type	Kensington
Cable lock slot	Yes
BIOS type	AMI
Sustainability certificates	ENERGY STAR, ErP
Compliance certificates	BSMI, CE, Federal Communications Commission (FCC), RCM, VCCI, ETL, CB, RoHS
Packaging data
Power cord included	Yes
Drivers included	Yes
AC adapter included	Yes
Package weight	2.1 kg
Indication
LED indicators	Power, HDD
Software
Windows operating systems supported	Windows 10, Windows 11
Linux operating systems supported	Yes
Management features
On/off switch	Yes
Sustainability
Sustainability certificates	ENERGY STAR, ErP
Power
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
AC adapter output voltage	19 V
AC adapter output current	6.32 A
Power supply type	External AC adapter
Power supply	120 W
Number of power supply units	1
Operational conditions
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	10 - 90%
Weight & dimensions
Width	165 mm
Depth	190 mm
Height	43 mm
Weight	1.3 kg
Package weight	2.1 kg
Packaging content
Quick start guide	Yes
Power cord included	Yes
Drivers included	Yes
AC adapter included	Yes
Other features
Chassis type	1.35L sized PC
