Collection: Data Projectors

EB-770Fi

Description

Agile USTi laser display
Project your vision, with a Full HD interactive large screen display up to 100" that will enhance engagement, learning and productivity.
Whatever the size of class or meeting room, unrestricted and interactive learning sessions are possible with this bright, compact and affordable touch-display solution.

The EB-770Fi's bright image, scalable up to 100", is clearly visible from every angle and at a distance, and content can easiliy be shared or streamed directly from multiple devices for the ultimate collaborative experience.

Specifications

Projector
Number of colours	1.07 billion colours
Projector brightness	4100 ANSI lumens
Projection technology	3LCD
Projector native resolution	1080p (1920x1080)
Screen size compatibility	1524 - 2540 mm (60 - 100")
Native aspect ratio	16:9
Contrast ratio (typical)	2500000:1
Vertical scan range	192 - 240 Hz
Keystone correction, vertical	-3 - 3°
Keystone correction, horizontal	-3 - 3°
Heat dissipation	895 BTU/h
Smart projector	No
Light source
Light source type	Laser
Service life of light source	20000 h
Service life of light source (economic mode)	30000 h
Lens system
Fixed focal length	3.7 mm
Zoom ratio	1.35:1
Zoom capability	Yes
Focus	Manual
Throw ratio	0.25 - 0.35:1
F-number (relative aperture)	1.6
Video
Analog signal format system	Not supported
Full HD	Yes
3D	No
Ports & interfaces
USB 2.0 Type-B ports quantity	2
VGA (D-Sub) ports quantity	2
HDMI ports quantity	3
USB 2.0 ports quantity	4
Composite video in	0
Microphone in	Yes
Serial interface type	RS-232C
DVI port	No
Component video (YPbPr/YCbCr) in	0
USB 2.0 Type-A ports quantity	2
Network
Ethernet LAN	Yes
Ethernet LAN data rates	10,100 Mbit/s
Wi-Fi	Yes
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Ethernet LAN (RJ-45) ports	1
Storage
Card reader integrated	No
Features
Interactive	Yes
Interactive input supported	Interactive pen/Touch
Noise level	37 dB
Noise level (economic mode)	27 dB
Multimedia
Built-in speaker(s)	Yes
RMS rated power	16 W
Design
Market positioning	Presentation
Product type	Ultra short throw projector
Product colour	White
Cable lock slot type	Kensington
Cable lock slot	Yes
Placement	Ceiling, Desktop, Wall
Power
Power source	AC
Power consumption (typical)	197 W
Power consumption (standby)	0.5 W
Power consumption (PowerSave)	199 W
Operational conditions
Storage temperature (T-T)	-10 - 60 °C
Operating relative humidity (H-H)	20 - 80%
Storage relative humidity (H-H)	10 - 90%
Weight & dimensions
Width	356 mm
Depth	395 mm
Height	133 mm
Weight	6 kg
Packaging content
Remote control included	Yes
Cables included	AC, USB
Batteries included	Yes
Other features
F-number (relative aperture)	1.6

EB-W55

Key Features

• High visibility large display
• Brighter, vivid projection
• Long-lasting solution
• Built-in speakers
• Enhanced connectivity
• Refreshingly easy setup

Description

Experience immersive entertainment and dynamic business presentations with this affordable WXGA lamp projector. Compact and lightweight with an easy setup, it offers high-tech features and impressive large display up to 320 inches. Thanks to Epson's 3LCD technology with 4,000 lumens Colour Light Output (CLO), you will enjoy vibrant and detailed lifelike images, even in bright ambient light rooms

Affordable, high visibility large displays
Bring the big-screen experience to your home, home office, or small business with this affordable yet feature-packed WXGA lamp projector. Enjoy immersive entertainment or deliver dynamic business presentations on a impressive large display of up to 320 inches.

Superior image quality
With an impressive 4,000 lumens of brightness and a 16,000:1 contrast ratio, this WXGA lamp projector delivers vivid, lifelike images with defined shadow detail. Powered by Epson's 3LCD technology, it offers up to three times brighter colours compared to 1-chip DLP projectors*.

Long-lasting solution
With this model's long-lasting lamp light source, you can enjoy a big screen experience for up to 18 years*

Built-in speakers
The built-in 2W mono speaker delivers powerful sound, ensuring clear audio even in larger rooms, so you don’t need to prepare additional speakers

Enhanced connectivity
Equipped with 2x HDMI ports and WiFi 6E to easily connect multiple devices and ensure faster communication speeds*

Refreshingly easy setup
Enjoy effortless setup with the auto power-on function, which detects signals from connected devices and starts automatically, ensuring an easy to use experience

Specifications

Projector
Projector brightness	4000 ANSI lumens
Projection technology	3LCD
Projector native resolution	WXGA (1200x800)
Screen size compatibility	838.2 - 8128 mm (33 - 320")
Native aspect ratio	16:10
Projection distance	1.68 - 2.02 m
Contrast ratio (typical)	16000:1
Projector brightness (economic mode)	2600 ANSI lumens
Matrix size	1.5 cm (0.59")
Keystone correction, vertical	-30 - 30°
Keystone correction, horizontal	-30 - 30°
Light source
Light source type	Lamp
Service life of light source	6000 h
Lamp type	UHE
Lamp power	210 W
Service life of light source (economic mode)	12000 h
Lens system
Zoom ratio	1.2:1
Focus	Manual
Focal length range	16.9 - 20.28 mm
Aperture range (F-F)	1.49 - 1.72
Throw ratio	1.30 - 1.56:1
Zoom type	Manual
Video
Analog signal format system	Not supported
Full HD	No
3D	No
Ports & interfaces
VGA (D-Sub) ports quantity	0
HDMI ports quantity	2
Composite video in	0
Audio (L/R) in	0
DVI port	No
Component video (YPbPr/YCbCr) in	0
Service port type	USB Type-B
USB 2.0 Type-A ports quantity	1
Network
Smart TV	No
Ethernet LAN	No
Wi-Fi	Yes
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Storage
Card reader integrated	No
Features
Interactive	No
Preset modes	Blackboard, Cinema, Dynamic, sRGB
Password protection	Yes
Noise level	37 dB
Noise level (economic mode)	28 dB
Multimedia
Built-in speaker(s)	Yes
Number of built-in speakers	1
RMS rated power	2 W
Design
Market positioning	Home cinema
Product colour	White
Cable lock slot type	Kensington
Cable lock slot	Yes
Placement	Ceiling, Desktop
Display
Built-in display	No
Power
Power source	AC
Power consumption (typical)	231 W
Power consumption (PowerSave)	0.3 W
Operational conditions
Operating temperature (T-T)	5 - 35 °C
Storage temperature (T-T)	-10 - 60 °C
Operating relative humidity (H-H)	41 - 95%
Storage relative humidity (H-H)	10 - 90%
Weight & dimensions
Width	302 mm
Depth	234 mm
Height	87 mm
Weight	2.6 kg
Packaging content
Remote control included	Yes
Cables included	AC
Batteries included	Yes

Ultra Short Throw Projectors

Description

- Up to 3x brighter colours and reliable performance1 – 3LCD, 3-chip technology. Look for both high colour brightness and high white brightness
- Lamp-free laser light source – provides up to 20,000 hours of virtually maintenance free operation, with the added benefits of higher image contrast and instant ON/OFF
- 1080p resolution – for Full HD presentations, videos, images, digital signage and more
- Amazing colour brightness – up to 4,100 lumens colour brightness and 4,100 lumens white brightness
- Miracast support – project your smartphone or tablet screens without a cable connection
- Large image size – displays large true-to-life images up to 150" in a convenient ultra short throw design
- Flexible display – 16:9 display with additional support for ultra wide 16:6 and 21:9 formats; ideal for large, multi-device, split screen images
- Captivating sound – enjoy a built-in stereo speaker up to 16 W for life-like sound
- Simple set-up – easily project wall-sized images — built-in edge blending features for easy, scalable projection

EB-770F 1080p 3LCD Ultra Short Throw Lamp-Free Laser Display
The large, easy-to-read HD display for dynamic classroom environments

True-to-life images
With 3-chip 3LCD technology and 4,100 lumens of colour and white brightness

Incredible image quality
Delivers Full HD 1080p resolution for amazing clarity and readability

No lamps to replace ever
A solid-state, 20,000-hour, virtually maintenance-free laser light source

Big screen for small spaces
Displays large true-to-life images up to 150" in a convenient ultra short throw design

Simple, flexible installation
In landscape or portrait, 360-degree placement capabilities allow for mounting or installing in nearly any position

Specifications

Projector
Number of colours	1.07 billion colours
Projector brightness	4100 ANSI lumens
Projection technology	3LCD
Projector native resolution	1080p (1920x1080)
Screen size compatibility	1447.8 - 3810 mm (57 - 150")
Native aspect ratio	16:9
Contrast ratio (typical)	2500000:1
Keystone correction, vertical	-3 - 3°
Keystone correction, horizontal	-3 - 3°
Smart projector	No
Light source
Light source type	Laser
Lens system
Fixed focal length	3.7 mm
Zoom capability	Yes
Focus	Manual
Throw ratio	0.25
Video
Analog signal format system	Not supported
Full HD	Yes
3D	No
Ports & interfaces
VGA (D-Sub) ports quantity	3
HDMI ports quantity	3
USB 2.0 ports quantity	2
Composite video in	0
Microphone in	Yes
Serial interface type	RS-232C
DVI port	No
Component video (YPbPr/YCbCr) in	0
Network
Smart TV	No
Ethernet LAN	Yes
Wi-Fi	Yes
Miracast	Yes
Storage
Card reader integrated	No
Features
Interactive	No
Noise level	37 dB
Noise level (economic mode)	27 dB
Multimedia
Built-in speaker(s)	Yes
Number of built-in speakers	1
RMS rated power	16 W
Design
Market positioning	Education
Product type	Ultra short throw projector
Product colour	White
Cable lock slot type	Kensington
Cable lock slot	Yes
Display
Built-in display	Yes
Display	LCD
Display diagonal	1.57 cm (0.62")
Power
Power source	AC
Power consumption (typical)	263 W
Power consumption (standby)	2 W
Auto power off	Yes
Weight & dimensions
Width	357 mm
Depth	395 mm
Height	165 mm
Weight	5.9 kg
Packaging content
Remote control included	Yes
Cables included	AC
Batteries included	Yes
