Samsung LH55OMNDSGBXXY Signage Display Digital signage flat panel 139.7 cm (55") LCD Wi-Fi 3000 cd/m² Full HD Black Built-in processor Tizen 5.0

55" OMN-S Series FHD Window Signage Display OM55N-S

Key Features

• Present bright content on a dual-display
• Modernize space with flexible design
• Maximize operational efficiency

Description

Present bright content on a dual-display
Dual-display, double the impact. Engineered to enhance multiple environments, maintaining picture integrity on the window-facing side even in direct sunlight, while delivering information concisely in-store for comprehensive customer engagement.

Modernize space with flexible design
Choose the position of your display with multiple installation options, complementing any environment with a flexible, smart design.

Maximize operational efficiency
A double-sided display allows content on both sides, all powered by just one electric power cord and one LAN cable for minimal clutter and maximized energy efficiency.

Streamline content management
The OMN-DS series’ embedded MagicINFO Player S7, backed by the powerful TIZEN operating system, boosts the display’s overall performance, allowing for easy content management and ensuring seamless content transition and playback.

Durable Performance
With IP5X-validated dust protection and embedded, proprietary functionality that mitigates overheating, the OMN-DS series continuously provides robust durability.

Clean Cable Configuration
Connectivity cover keeps connections clean and organized. Embedded Wi-Fi also allows for updates without the need for any additional messy cables.

Specifications

Display
Dynamic contrast ratio marketing name	Mega Contrast
Display diagonal	139.7 cm (55")
Display resolution	1920 x 1080 pixels
Display brightness	3000 cd/m²
HD type	Full HD
Response time	6 ms
Contrast ratio (typical)	6000:1
Viewing angle, horizontal	178°
Viewing angle, vertical	178°
Pixel pitch	0.63 x 0.63 mm
Vertical scan range	24 - 75 Hz
Touchscreen	No
Panel type	VA
Horizontal scan range	15 - 135 kHz
Display technology	LCD
Colour gamut	72%
RGB colour space	NTSC
Pixel frequency (max)	594 MHz
Ports & interfaces
Remote (IR) input	1
Ethernet LAN	Yes
HDMI ports quantity	2
USB port	Yes
HDMI version	2.0
DVI port	No
Ethernet LAN (RJ-45) ports	1
RS-232 interface	Yes
Wi-Fi	Yes
USB ports quantity	2
Infrared data port	Yes
DisplayPorts quantity	0
Design
Product design	Digital signage flat panel
Product colour	Black
Placement supported	Indoor/outdoor
Orientation	Vertical
Bezel width (top)	2.28 cm
Bezel width (side)	2.28 cm
Bezel width (bottom)	2.28 cm
Certification	Class A 60950-1
Screen shape	Flat
Performance
Purpose	Universal
HDCP	Yes
HDCP version	2.2
Wi-Fi	Yes
Power
Power consumption (typical)	500 W
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (sleep)	0.5 W
Computer system
Computer system	Yes
Computer system type	System on Chip (SoC)
Operating system installed	Tizen 5.0
Built-in processor	Yes
Weight & dimensions
Display width	726.8 mm
Display depth	69.5 mm
Display height	1299 mm
Display weight	42 kg
Packaging data
Package width	940 mm
Package depth	367 mm
Package height	1466 mm
Package volume	52000 cm³
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80%
Certificates
Certification	Class A 60950-1
Network
Ethernet LAN	Yes
Wi-Fi	Yes
Thin Client
Operating system installed	Tizen 5.0
Technical details
RS-232 input ports	1
Panel type	VA
Other features
Wi-Fi	Yes
RS-232 input ports	1
Panel type	VA
Flash memory	8000 MB
Display technology	LCD
Bezel width (top)	2.28 cm
Bezel width (side)	2.28 cm
Bezel width (bottom)	2.28 cm
