Work in your comfort zone
Minimize movement and maximize your comfort with ERGO M575S wireless trackball - now with quiet clicks. With thumb control you won’t need to move your arm to move the cursor, so your hand stays fully supported on the sculpted ergonomic design. A good and snug fit for most hand sizes.
Less movement. More comfort.
Keep your hand and forearm relaxed with thumb control for all-day comfort. The sculpted ergonomic design of ERGO M575S puts your forearm in a more natural posture, and reduces the muscle strain in your forearm by 25%.
Save space with thumb control
As you won’t need to move your hand to move the cursor, this wireless trackball is ideal for small or busy setups - plus, it works on any surface.
Certified by ergonomists
ERGO M575S was developed with Logi Ergo Lab experts and is user-tested and certified by ergonomists to reduce muscle strain and work in a more natural posture.
Specs and Compatibility
Dimensions
Height: 134 mm
Width: 100 mm
Depth: 48 mm
Weight: 145 g
Technical Specifications
Sensor Technology
Sensor Technology: Logitech Advanced Optical Tracking
Nominal value: 400 DPI
Max value: Up to 2000 DPI
Buttons
Number of Buttons: 5 (Left/Right-click, Back/Forward, Scroll-wheel with middle click)
Number of customizable buttons: 3 (Back/Forward, Middle click)
Customization app
Supported by Logi Options+ on Windows and macOS
Requires Logi Options+ app, available for recent versions of Windows and macOS at logi.com/optionsplus.
Battery
Battery type: 1 x AA battery (included)
Battery life: Up to 18 months
Connection Type
USB Receiver
Bluetooth Low Energy Technology
Wireless range
10 m wireless range
Sustainability
Graphite/Black plastics: 52% post-consumer recycled material
Off-white plastics: 21% post-consumer recycled material
Paper Packaging: FSC™-certified
System Requirements
Logi Bolt USB Receiver
Required: USB-A port , Windows 10, 11 or later , macOS 12 or later , Linux
, ChromeOS
Bluetooth
Required: Bluetooth Low Energy , Windows 10, 11 or later , macOS 12 or later , Linux
, ChromeOS
, iPadOS 15 or later
, Android 12 or later
Internet access required to download optional customization app Logi Options+
Warranty Information
1-Year Limited Hardware Warranty
Specifications
Mouse
Number of programmable buttons
3
Device interface
Bluetooth
Buttons durability (million clicks)
3
Buttons quantity
5
Movement detection technology
Trackball
Purpose
Office
Wireless range
10 m
Movement resolution
2000 DPI
Scrolling directions
Vertical
Scroll type
Wheel
Response time
11.25 ms
Programmable mouse buttons
Yes
Polling rate
88,133 Hz
Number of scroll wheels
1
Buttons type
Pressed buttons
Button functions
Back, Forward
Bluetooth Low Energy (BLE)
Yes
Silent click
Yes
Input device
Number of programmable buttons
3
Device interface
Bluetooth
Buttons quantity
5
Movement detection technology
Trackball
Purpose
Office
Wireless range
10 m
Movement resolution
2000 DPI
Scrolling directions
Vertical
Scroll type
Wheel
Response time
11.25 ms
Programmable mouse buttons
Yes
Polling rate
88,133 Hz
Number of scroll wheels
1
Buttons type
Pressed buttons
Button functions
Back, Forward
Design
Product colour
Graphite, Blue
Form factor
Right-hand
Material
Acrylonitrile butadiene styrene (ABS)
Wireless receiver interface
USB Type-A
Surface coloration
Monochromatic
Receiver type
Nano receiver
Ergonomic design
Yes
Ergonomics
Buttons durability (million clicks)
3
Wireless range
10 m
Polling rate
88,133 Hz
Ergonomic design
Yes
Power
Battery capacity
2000 mAh
Power source
Batteries
Number of batteries supported
1
Battery type
AA
Service life of battery
18 month(s)
USB Type-C charging port
No
USB Power Delivery (USB PD)
No
System requirements
Mobile operating systems supported
Android 12.0, iPadOS
Windows operating systems supported
Windows 10, Windows 11
Mac operating systems supported
Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura, Mac OS X 14.0 Sonoma
Linux operating systems supported
Yes
Weight & dimensions
Width
100 mm
Depth
48 mm
Height
134 mm
Weight
145 g
Packaging data
AC adapter included
No
Package width
50 mm
Package depth
105 mm
Package height
142 mm
Package weight
225 g
Package type
Box
Quantity per pack
1 pc(s)
Receiver included
Yes
Batteries included
Yes
Wireless receiver interface
USB Type-A
User guide
Yes
Receiver type
Nano receiver
Packaging content
Receiver included
Yes
Batteries included
Yes
Wireless receiver interface
USB Type-A
User guide
Yes
Receiver type
Nano receiver
Technical details
Packaging content
Wireless Trackball Mouse
Logi Bolt Receiver
1 x AA Battery
Document
Sustainability certificates
Forest Stewardship Council (FSC)
Warranty period
2 year(s)
Sustainability
Sustainability certificates
Forest Stewardship Council (FSC)
Post-consumer recycled plastic
52%
Logistics data
Quantity per pack
1 pc(s)
Other features
Packaging content
Wireless Trackball Mouse
Logi Bolt Receiver
1 x AA Battery
Document
