Lenovo ThinkCentre M70q Gen 6 Intel Core Ultra 5 225T 16 GB DDR5-SDRAM 512 GB SSD Windows 11 Pro Mini PC Black

Intel Core Ultra 5 225T, 10C (6P + 4E)/10T, Max Turbo up to 4.9GHz, 20MB Intel Smart Cache, 2x 8GB SODIMM DDR5-5600, 512GB SSD M.2 2280 PCIe 4.0x4 NVMe Opal, Intel Graphics, Realtek Wi-Fi 7 RTL8922AE 802.11be 2x2+ BT5.4, Windows 11 Pro

Key Features

• Intel Core Ultra 5 225T, 10C (6P + 4E)/10T, Max Turbo up to 4.9GHz, 20MB Intel Smart Cache
• 2x 8GB SODIMM DDR5-5600
• 512GB SSD M.2 2280 PCIe 4.0x4 NVMe Opal
• Intel Graphics
• Windows 11 Pro

Description

LENOVO ThinkCentre M70q G6 Tiny Desktop PC Inte U5-225T 16GB DDR5 512GB SSD Windows 11 Pro 3yrs Onsite Wty Keyboard Mouse WiFi+BT LAN

Processor Intel® Core™ Ultra 5 225T, 10C (6P + 4E) / 10T, Max Turbo up to 4.9GHz, 20MB
AI PC Category AI PC
NPU Integrated Intel® AI Boost, up to 13 TOPS
Graphics Integrated Intel® Graphics
Chipset Intel® Q870 Chipset
Memory 2x 8GB SO-DIMM DDR5-5600
Memory Slots Two DDR5 SO-DIMM slots, dual-channel capable
Max Memory Up to 64GB (2x 32GB DDR5 SO-DIMM)
Storage 512GB SSD M.2 2280 PCIe® 4.0x4 NVMe® Opal
Storage Support Up to two drives, 2x M.2 2280 SSD • M.2 2280 SSD up to 2TB
RAID Preset None
Card Reader No card reader
Optical None
Audio Chip High Definition (HD) Audio, Realtek® ALC233VB or Conexant CX11771 codec
Speakers 2Wx1
Power Supply 90W 89% Adapter
DESIGN
Keyboard USB Traditional Keyboard, Black, English
Mouse USB Calliope Mouse, Black
Expansion Slots Three M.2 slots (one for WLAN, two for SSD / discrete NPU)
Case Color Black
Stand None
Adapter Cage None
Toolless Chassis Screw None
Dust Filter None
Mounting None
IO Box None
Pen Pen Not Supported
Form Factor Tiny (1L)
Dimensions (WxDxH) 179 x 182.9 x 36.5 mm with rubber feet (7.05 x 7.2 x 1.44 inches with rubber feet)
Weight Around 1.18 kg (2.6 lbs)
CONNECTIVITY
WLAN + Bluetooth Realtek® Wi-Fi® 7 RTL8922AE, 802.11be 2x2 + BT5.4
WWAN Non-WWAN
Ethernet Integrated 100/1000M
Front Ports 1x USB-C® (USB 10Gbps / USB 3.2 Gen 2), data transfer only
2x USB-A (USB 10Gbps / USB 3.2 Gen 2), one supports Always On and 5V@2.1A charging
1x headphone / microphone combo jack (3.5mm)
Rear Ports 2x USB-A (USB 10Gbps / USB 3.2 Gen 2)
2x USB-A (USB 5Gbps / USB 3.2 Gen 1), one supports Smart Power On
1x HDMI® 2.1 TMDS
1x DisplayPort™ 1.4a (HBR2)
1x Ethernet (GbE RJ-45)
Optional Rear Ports (configured) None
SECURITY & PRIVACY
Security Chip Discrete TPM 2.0, TCG certified, FIPS 140-2 certified
Fingerprint Reader No fingerprint reader
Physical Locks Kensington® Security Slot™, 3 x 7 mm
Kensington Cable Lock None
Chassis Intrusion Switch Chassis Intrusion Switch
MANAGEABILITY
System Management Non-vPro®
SERVICE
Base Warranty 3-year, Onsite
Included Upgrade None
CERTIFICATIONS
Green Certifications ENERGY STAR® 9.0
RoHS compliant
TCO Certified 10.0
Mil-Spec Test MIL-STD-810H military test passed (Low Pressure [Altitude], High Temperature, Low Temperature, Temperature Shock, Humidity, Sand and Dust, Vibration, Shock, Solar Radiation, Contamination by Fluids, Salt Fog)

Specifications

Processor
Processor family	Intel Core Ultra 5
Processor manufacturer	Intel
Processor model	225T
Processor cores	10
Processor threads	10
Memory
Internal memory	16 GB
Internal memory type	DDR5-SDRAM
Maximum internal memory	64 GB
Memory layout (slots x size)	2 x 8 GB
Memory slots	2x SO-DIMM
Memory clock speed	5600 MHz
Storage
Total storage capacity	512 GB
Optical drive type	No
Card reader integrated	No
Storage media	SSD
Number of SSDs installed	1
SSD capacity	512 GB
SSD interface	PCI Express 4.0
SSD form factor	M.2
Total SSDs capacity	512 GB
NVMe	Yes
Graphics
Discrete graphics card	No
On-board graphics card family	Intel® Graphics
Discrete graphics card model	Not available
On-board graphics card model	Intel® Graphics
On-board graphics card	Yes
On-board GPU manufacturer	Intel
Performance
Product type	Mini PC
Motherboard chipset	Intel® Q870
Trusted Platform Module (TPM)	Yes
Audio chip	Realtek ALC233VB
Number of speakers	1
Audio system	High Definition Audio
Optical drive
Optical drive type	No
Network
Ethernet LAN	Yes
Ethernet LAN data rates	100,1000 Mbit/s
Wi-Fi	Yes
Wi-Fi standards	Wi-Fi 7 (802.11be)
Bluetooth	Yes
Bluetooth version	5.4
Top Wi-Fi standard	Wi-Fi 7 (802.11be)
Antenna type	2x2
Ports & interfaces
Combo headphone/mic port	Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	4
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	1
Thunderbolt 3 ports quantity	0
USB 2.0 ports quantity	0
HDMI ports quantity	1
HDMI version	2.1
DisplayPorts quantity	1
Ethernet LAN (RJ-45) ports	1
Power
Power supply	90 W
Design
Product colour	Black
Volume	1 L
Chassis type	Mini PC
Cable lock slot	Yes
Cable lock slot type	Kensington
Software
Operating system installed	Windows 11 Pro
Operating system language	English
Audio
Audio chip	Realtek ALC233VB
Number of speakers	1
Audio system	High Definition Audio
Weight & dimensions
Volume	1 L
Width	179 mm
Depth	182.9 mm
Height	36.5 mm
Weight	1.18 kg
Packaging content
Mouse included	Yes
Keyboard included	Yes
Mouse connectivity	Wired
Keyboard connectivity	Wired
Certificates
Certification	ENERGY STAR,TCO,RoHS
Keyboard
Keyboard connectivity	Wired
Other features
Number of speakers	1
Processor manufacturer	Intel
Trusted Platform Module (TPM)	Yes
On-board graphics card	Yes
