86.7cm (34.14") Wide Quad HD 3440 x 1440 W-LED IPS, 21:9, 300cd/m², 1.07B, 6ms, 178°/178°, 1000:1
Key Features
USB, HDMI, DisplayPort
Description
ThinkVision P34w-20 hub monitor upgrades your view with a premium visual experience on a 34,14-inch curved screen with a WQHD 3440 x 1440 resolution for a wide viewing angle In-Plane Switching panel that lets you see all the fine details and vibrant colors from any angle. With the P34w-20 you get true-to life color accuracy, make multi-tasking a breeze with advanced tools for collaboration, and enhance workplace productivity and connectivity with the power of USB Type-C capabilities. Never miss a shade with a 99% sRGB delta E<2 for reliable color accuracy straight out of the box, while Natural Low Blue Light technology reduces harmful blue light emissions to optimize eye comfort without color distortion.
Specifications
Display
Display brightness (typical)
300 cd/m²
Screen shape
Curved
Display number of colours
1.07 billion colours
Native aspect ratio
21:9
Maximum refresh rate
60 Hz
Display diagonal
86.7 cm (34.1")
Response time
6 ms
Display resolution
3440 x 1440 pixels
Display technology
LED
Contrast ratio (typical)
1000:1
Contrast ratio (dynamic)
3000000:1
Viewing angle, horizontal
178°
Viewing angle, vertical
178°
Pixel pitch
0.2325 x 0.2325 mm
Viewable size, horizontal
80 cm
Viewable size, vertical
33.5 cm
HD type
Wide Quad HD
Pixel density
109 ppi
Colour gamut
99%
Backlight type
W-LED
Response time (fast)
4 ms
Touchscreen
No
High Dynamic Range (HDR) supported
Yes
Panel type
IPS
Colour depth
10 bit
Screen curvature rating
3800R
Colour gamut standard
sRGB
Anti-glare screen
Yes
Performance
Low Blue Light technology
Yes
Flicker-free technology
Yes
Multimedia
Number of speakers
2
Built-in speaker(s)
Yes
RMS rated power
6 W
Design
Product colour
Black
Certification
ENERGY STAR
CCC
TCO 8.0
TCO Edge 2.0
EPEAT Gold
RoHS
TÜV
Colour name
Raven Black
Ports & interfaces
Built-in USB hub
Yes
USB hub version
3.2 Gen 1 (3.1 Gen 1)
USB upstream port type
USB Type-B, USB Type-C
Number of upstream ports
2
USB Type-A downstream ports quantity
3
USB Type-C downstream ports quantity
1
VGA (D-Sub) ports quantity
0
HDMI ports quantity
2
DisplayPorts quantity
2
Audio output
Yes
Headphone outputs
1
Headphone connectivity
3.5 mm
Headphone out
Yes
HDMI
Yes
HDMI version
2.0
DisplayPort version
1.2
USB Power Delivery (USB PD)
Yes
USB Power Delivery up to
100 W
USB Type-C DisplayPort Alternate Mode
Yes
Number of USB Type-B upstream ports quantity
1
Number of USB Type-C upstream ports quantity
1
Built-in KVM switch
Yes
Ethernet LAN
Yes
Network
Ethernet LAN
Yes
Ergonomics
VESA mounting
Yes
Cable lock slot
Yes
Panel mounting interface
100 x 100 mm
Swivelling
Yes
Swivel angle range
-45 - 45°
Tilt angle range
-5 - 35°
Height adjustment
Yes
On Screen Display (OSD)
Yes
Cable lock slot type
Kensington
Tilt adjustment
Yes
Adjustable height (max)
15 cm
Power
AC input voltage
100 - 240 V
Power consumption (max)
230 W
Power consumption (standby)
0.5 W
Power consumption (typical)
36 W
Power consumption (off)
0.3 W
Energy efficiency scale
A to G
Energy efficiency class (SDR)
F
Energy efficiency class (HDR)
G
Energy consumption (SDR) per 1000 hours
32 kWh
Energy consumption (HDR) per 1000 hours
34 kWh
Weight & dimensions
Width (with stand)
817.3 mm
Depth (with stand)
245 mm
Height (with stand)
621.4 mm
Bezel width (side)
9.5 mm
Bezel width (top)
9.5 mm
Bezel width (bottom)
2.84 cm
Width (without stand)
817.3 mm
Height (without stand)
372.7 mm
Depth (without stand)
76.8 mm
Weight (with stand)
10.8 kg
Weight (without stand)
7.4 kg
Package width
937 mm
Package depth
220 mm
Package height
475 mm
Package weight
15.5 kg
Packaging data
Package width
937 mm
Package depth
220 mm
Package height
475 mm
Package weight
15.5 kg
Stand included
Yes
Cables included
AC, USB Type-C
Packaging content
Stand included
Yes
Cables included
AC, USB Type-C
Other features
Certification
ENERGY STAR
CCC
TCO 8.0
TCO Edge 2.0
EPEAT Gold
RoHS
TÜV
Power consumption (max)
230 W
Width (without stand)
817.3 mm
Height (without stand)
372.7 mm
HDMI
Yes
Depth (without stand)
76.8 mm
USB Power Delivery up to
100 W
Energy efficiency scale
A to G
USB Type-C DisplayPort Alternate Mode
Yes
Ethernet LAN
Yes
Touchscreen
No
USB Power Delivery (USB PD)
Yes
Certificates
Certification
ENERGY STAR
CCC
TCO 8.0
TCO Edge 2.0
EPEAT Gold
RoHS
TÜV
