Cooler Master MAX Series NR200P MAX V2 Tower Grey 850 W
Cooler Master MAX Series NR200P MAX V2 Tower Grey 850 W
SKU: NR200PV2-MCNN85-SL0
Availability:
Sale
Sold out
In Stock
10+ in stock
Regular price
$526.99
Price:
$526.99
Regular price
$561.00
Taxes included.
IN STOCK AT WAREHOUSE DELIVERY TO STORE 2-4 DAYS.
Couldn't load pickup availability
Mini-ITX, 18.25L, 2.5", 3.5", 2 x USB 3.2 Gen 1, 1x USB 3.2 Gen2 x 2 Type C, 3.5mm, 2 x 140mm/280mm, V SFX Gold 850W ATX 3.0,
NR200P MAX V2
STREAMLINE YOUR BUILD EXPERIENCE
ENHANCE SUPPORT FOR HIGH-END ITX SYSTEMS
The NR200P MAX V2 enhances GPU support capability up to 356.7mm and includes a GPU holder and a 12VHPWR power cable for the latest GPUs. Combined with tailor-made thermal and power delivery solutions, the NR200P MAX V2 comprehensively satisfies users' demands for a high-end ITX system with a 'ready-to-go' package
NCORE-PATTERNED' STEEL LEFT SIDE PANEL AND TEMPERED GLASS VENTILATED OPTIONS
The NR200P MAX V2 is equipped with an 'Ncore-patterned' side steel panel. This upgrade assists the system in increasing ventilation, ensuring that power-hungry builds stay cool and run more efficiently. Additionally, the edge-to-edge tempered glass panel provides a premium aesthetic.
TAILOR-MADE PREMIUM COOLING AND ATX 3.0 SUPPORTED POWER DELIVERY
Next-gen systems are becoming more and more power-hungry and to power it all, NR200P MAX V2 implements an ATX 3.0 850W Gold-certified PSU with custom-length textured cables specifically designed to cover all performance needs.
A 280mm radiator, two pre-installed SickleFlow PWM 140mm fans and Cooler Master's highly acclaimed 3rd generation pump/CPU block provide reliable cooling for the CPU. AMD sockets up to AM4 and AM5 and Intel sockets up to LGA1700 are fully supported.
TRIPLE-SLOT GPU SUPPORT
The NR200P MAX V2 supports triple-slot GPUs up to 357.6mm in length and 160mm in height. Additionally, this chassis has been specifically designed for vertically mounted GPUs to ensure powerful performance.
VERSATILE HARD DRIVE SUPPORT
NR200P MAX V2 provides two dedicated 2.5” hard drive mounting locations. For extra storage, two optional 3.5” hard drive mounting locations may be available depending on hardware configuration.
PREMIUM PCIE GEN4 RISER CABLE INCLUDED
NR200P MAX V2 comes equipped with a premium shielded PCIe Gen4 Riser Cable to ensure both maximum compatibility and performance with all graphics cards.
PERFORMANCE UNBOUNDED
The pre-installed, 80 Plus ATX 3.0 Gold efficiency PSU features 16AWG PCIe full-modular, high efficiency cables tailor-made to allow ease of installation without the hassle of cable management. Tailor-made to a small form factor, this PSU allows clearance for the largest, widest graphics cards while making the most of NR200P MAX V2’s 18 liter chassis.
COOLING EFFICIENCY BEYOND COMPARE
NR200P MAX V2’s built-in 280mm radiator boasts unmatched cooling efficiency owing to a 25% increase in aluminum fin surface area.
Compatible with a wide variety of Intel and AMD sockets (all brackets included), the AIO’s upgraded Gen3 dual-chamber pump is bound to keep any CPU running at optimum performance. Included Sickleflow 140 Non-LED fans utilize a two-tier sealing mechanism to prevent dust accumulation, resulting in longer serviceable life span and silent performance.
ATX 3.0 COMPATIBLE
Cooler Master's V Gold power solutions, renowned for their extraordinary performance delivery and high reliability, have been upgraded to support ATX 3.0. This ensures that the system is capable of satisfying all levels of performance needs.
Build Small. Play Big.
This case is compatible with SFF-Ready Enthusiast GeForce cards, so you can pack high performance into a smaller footprint. Look for SFF-Ready Enthusiast GeForce Cards to get a sure fit and streamline your PC build.
View full details
Key Features
- Comprehensive support for the latest GPUs
- Increase ventilation with New side panel
- Preinstalled ATX 3.0 PSU with 12VHPWR cable
- Featured a USB typeC port
Description
Acquire the Premium ITX EffortlesslyNR200P MAX V2
STREAMLINE YOUR BUILD EXPERIENCE
ENHANCE SUPPORT FOR HIGH-END ITX SYSTEMS
The NR200P MAX V2 enhances GPU support capability up to 356.7mm and includes a GPU holder and a 12VHPWR power cable for the latest GPUs. Combined with tailor-made thermal and power delivery solutions, the NR200P MAX V2 comprehensively satisfies users' demands for a high-end ITX system with a 'ready-to-go' package
NCORE-PATTERNED' STEEL LEFT SIDE PANEL AND TEMPERED GLASS VENTILATED OPTIONS
The NR200P MAX V2 is equipped with an 'Ncore-patterned' side steel panel. This upgrade assists the system in increasing ventilation, ensuring that power-hungry builds stay cool and run more efficiently. Additionally, the edge-to-edge tempered glass panel provides a premium aesthetic.
TAILOR-MADE PREMIUM COOLING AND ATX 3.0 SUPPORTED POWER DELIVERY
Next-gen systems are becoming more and more power-hungry and to power it all, NR200P MAX V2 implements an ATX 3.0 850W Gold-certified PSU with custom-length textured cables specifically designed to cover all performance needs.
A 280mm radiator, two pre-installed SickleFlow PWM 140mm fans and Cooler Master's highly acclaimed 3rd generation pump/CPU block provide reliable cooling for the CPU. AMD sockets up to AM4 and AM5 and Intel sockets up to LGA1700 are fully supported.
TRIPLE-SLOT GPU SUPPORT
The NR200P MAX V2 supports triple-slot GPUs up to 357.6mm in length and 160mm in height. Additionally, this chassis has been specifically designed for vertically mounted GPUs to ensure powerful performance.
VERSATILE HARD DRIVE SUPPORT
NR200P MAX V2 provides two dedicated 2.5” hard drive mounting locations. For extra storage, two optional 3.5” hard drive mounting locations may be available depending on hardware configuration.
PREMIUM PCIE GEN4 RISER CABLE INCLUDED
NR200P MAX V2 comes equipped with a premium shielded PCIe Gen4 Riser Cable to ensure both maximum compatibility and performance with all graphics cards.
PERFORMANCE UNBOUNDED
The pre-installed, 80 Plus ATX 3.0 Gold efficiency PSU features 16AWG PCIe full-modular, high efficiency cables tailor-made to allow ease of installation without the hassle of cable management. Tailor-made to a small form factor, this PSU allows clearance for the largest, widest graphics cards while making the most of NR200P MAX V2’s 18 liter chassis.
COOLING EFFICIENCY BEYOND COMPARE
NR200P MAX V2’s built-in 280mm radiator boasts unmatched cooling efficiency owing to a 25% increase in aluminum fin surface area.
Compatible with a wide variety of Intel and AMD sockets (all brackets included), the AIO’s upgraded Gen3 dual-chamber pump is bound to keep any CPU running at optimum performance. Included Sickleflow 140 Non-LED fans utilize a two-tier sealing mechanism to prevent dust accumulation, resulting in longer serviceable life span and silent performance.
ATX 3.0 COMPATIBLE
Cooler Master's V Gold power solutions, renowned for their extraordinary performance delivery and high reliability, have been upgraded to support ATX 3.0. This ensures that the system is capable of satisfying all levels of performance needs.
Build Small. Play Big.
This case is compatible with SFF-Ready Enthusiast GeForce cards, so you can pack high performance into a smaller footprint. Look for SFF-Ready Enthusiast GeForce Cards to get a sure fit and streamline your PC build.
Specifications
| Design | |
|---|---|
| Volume | 18.25 L |
| Fan connector | 4-pin |
| Anti-dust filter | Yes |
| Bearing type | Fluid bearing |
| Form factor | Tower |
| Type | PC |
| Material | Acrylonitrile butadiene styrene (ABS), Mesh, SGCC, Steel, Tempered glass |
| Number of 3.5" bays | 2 |
| Supported motherboard form factors | Mini-ITX |
| Product colour | Grey |
| Number of 2.5" bays | 2 |
| Side window | Yes |
| Number of expansion slots | 3 |
| Maximum CPU cooler height | 6.7 cm |
| Maximum graphics card length | 35.8 cm |
| Maximum PSU length | 13 cm |
| Power supply | |
| Supported power supply form factors | SFX, SFX-L |
| Power supply included | Yes |
| Power supply | 850 W |
| 80 PLUS certification | 80 PLUS Gold |
| ATX version | 3.0 |
| Ports & interfaces | |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| Fan connector | 4-pin |
| Audio input | Yes |
| Audio output | Yes |
| Cooling | |
| Top radiator installed | Yes |
| Top radiator sizes supported | 120,140,240,280 mm |
| Noise level (low speed) | 10 dB |
| Noise level (high speed) | 27 dB |
| Maximum airflow | 67 cfm |
| Fan rated voltage | 12 V |
| Fan rated current | 0.15 A |
| Top radiator fan size installed | 280 |
| Top fans installed | 2x 140 mm |
| Number of top fans supported (max) | 2 |
| Top fans diameters supported | 120,140 mm |
| Number of bottom fans supported (max) | 2 |
| Bottom fans diameters supported | 120 mm |
| Fan speed | 650 - 1400 RPM |
| Maximum air pressure | 2.25 mmH2O |
| Pulse-width modulation (PWM) support | Yes |
| Storage | |
| HDD/SSD combo cage | Yes |
| Supported HDD sizes | 2.5,3.5" |
| Packaging content | |
| Riser cable included | Yes |
| Weight & dimensions | |
| Volume | 18.25 L |
| Width | 185 mm |
| Depth | 377 mm |
| Height | 292 mm |
| Weight | 7.7 kg |
| Packaging data | |
| Package width | 288 mm |
| Package depth | 350 mm |
| Package height | 448 mm |
| Package weight | 9.5 kg |
| Other features | |
| Volume | 18.25 L |
| Maximum airflow | 67 cfm |
| Fan connector | 4-pin |
| Bearing type | Fluid bearing |
