Comsol CM24HDA laptop dock/port replicator Wired USB 3.2 Gen 1 (3.1 Gen 1) Type-C Grey

USB-C Dual HDMI Monitor 12 Port Docking Station

Key Features

• RUN DUAL MONITORS in extended desktop mode on Windows laptops and Chromebooks
• 4K ULTRA HD AND 1080P HD support for single or dual monitors at 60Hz*
• USB-C CHARGING supports USB-C chargers up to 140W and provides up to 90W of USB-C power for laptop charging#
• CONNECT two monitors, keyboard and mouse, multiple USB devices, a wired Gigabit network and headset or speakers
• UNIQUE DESIGN improves laptop airflow and includes a stowable USB-C connection cable

Description

Connect a Windows laptop or Chromebook to two monitors and multiple USB devices, all via a single USB-C connection

Specifications

Ports & interfaces
Combo headphone/mic port	Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	2
Connectivity technology	Wired
USB 2.0 ports quantity	0
Host interface	USB 3.2 Gen 1 (3.1 Gen 1) Type-C
Ethernet LAN (RJ-45) ports	1
HDMI ports quantity	2
Microphone in	No
Headphone outputs	0
USB Power Delivery (USB PD)	Yes
USB Power Delivery up to	90 W
Network
Ethernet LAN	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s
Ethernet LAN (RJ-45) ports	1
Performance
Maximum digital resolution	3840 x 2160 pixels
Number of displays supported	2
Product colour	Grey
Card reader integrated	Yes
Compatible memory cards	MicroSD (TransFlash), SD
Data transfer rate	5 Gbit/s
Certification	AS/NZS 62368-1:2022, RCM, EMC
HD type	4K Ultra HD
Maximum refresh rate	60 Hz
Storage
Card reader integrated	Yes
Compatible memory cards	MicroSD (TransFlash), SD
Power
Power source type	USB
Power connector	USB Type-C
Software
Windows operating systems supported	Yes
Mac operating systems supported	Yes
Other operating systems supported	ChromeOS
Weight & dimensions
Width	250 mm
Depth	55 mm
Height	16 mm
Weight	284 g
Design
Windows operating systems supported	Yes
Mac operating systems supported	Yes
Product colour	Grey
Certification	AS/NZS 62368-1:2022, RCM, EMC
Packaging data
Quantity per pack	1 pc(s)
Packaging content
Cables included	USB Type-C
Quantity per pack	1 pc(s)
Technical details
Warranty period	2 year(s)
