Collection: Products

UniFi Sliding Rack Rails, SGCC steel, for 600-1066 mm

Description

Adjustable sliding rails for UniFi rack-mount gear, designed for smooth sliding and flexible fit in 4-post racks.

Specifications

Features
Type	Rack rail
Maximum weight capacity	45 kg
Product colour	Grey
Compatibility	USW-Pro-XG-24 USW-Pro-XG-24-PoE USW-Pro-XG-48 USW-Pro-XG-48-PoE USW-Pro-HD-24 USW-Pro-XG-10-PoE USW-Pro-HD-24-PoE USW-Pro-XG-Aggregation
Housing material	SGCC
Weight & dimensions
Width	43 mm
Weight	2.5 kg
Height	21 mm
Depth	625 mm
Minimum rack depth supported	60 cm
Maximum rack depth supported	106.6 cm

DIN Rail Mount, Polycarbonate, 125.7 x 40.5 x 20.6 mm

Description

DIN rail mount for UniFi compact switches.

Specifications

Technical details
Material	Polycarbonate (PC)
Product colour	White
Compatibility	USW-Ultra (42W) USW-Flex-2.5G-8 USW-Ultra-60W (52W) USW-Flex-2.5G-8-PoE USW-Ultra-210W (202W)
Quantity per pack	1 pc(s)
Weight & dimensions
Weight	36.8 g
Width	40.5 mm
Depth	20.6 mm
Height	125.7 mm
Packaging data
Quantity per pack	1 pc(s)

Floating Mount, Polycarbonate, silicone rubber, 125.6 x 40.4 x 10.4 mm

Description

Sleek magnetic wall mount for UniFi compact switches.

Specifications

Technical details
Material	Polycarbonate (PC), Silicone
Product colour	White
Compatibility	USW-Flex-2.5G-8-PoE, USW-Flex-2.5G-8
Quantity per pack	1 pc(s)
Weight & dimensions
Weight	56.1 g
Width	40.4 mm
Depth	10.4 mm
Height	125.6 mm
Packaging data
Quantity per pack	1 pc(s)

Desktop, 2x 3.5" drive bays, 2.5 GbE RJ45 (2.5G/1G/100M/10M), 5 Gbps USB-C, PoE++, Quad-Core ARM Cortex-A55 at 1.7 GHz, Bluetooth 4.1, 1.47" color LCM

Description

UniFi Network Attached Storage with (2) 3.5" HDD bays, 2.5 GbE networking, USB-C connectivity, and an included PoE++ adapter, all in a compact footprint.

Specifications

Storage
Storage drives installed	No
Installed storage drive type	No
Supported storage drive types	HDD
Number of storage drives supported	2
Storage drive size	3.5"
RAID support	Yes
RAID levels	1
Hot-swap drive bays	No
Storage drive sizes supported	3.5"
Processor
Processor manufacturer	ARM
Processor architecture	ARM Cortex-A57
Processor family	Cortex-A
Processor model	Cortex-A57
Processor frequency	1.7 GHz
Processor cores	4
Memory
Internal memory	4 GB
Network
Ethernet LAN	Yes
Ethernet LAN data rates	10,100,1000,2500 Mbit/s
Ports & interfaces
USB port	Yes
Ethernet LAN (RJ-45) ports	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	1
Design
Chassis type	Desktop
Product colour	Black
Housing material	Polycarbonate (PC)
LED indicators	Status, System
Built-in display	Yes
Display type	LCM
Performance
Type	NAS
Backup function	Yes
Web-based management	Yes
Other operating systems supported	Android, iOS
Software
Other operating systems supported	Android, iOS
Power
Power consumption (max)	60 W
Power supply location	External
Weight & dimensions
Width	129 mm
Depth	135 mm
Height	223.7 mm
Weight	1.3 kg
Technical details
Compliance certificates	CE, Federal Communications Commission (FCC), Industry Canada (IC), National Defense Authorization Act (NDAA)
Packaging content
External power adapter	Yes
Cables included	Power
Power cables quantity	1
Operational conditions
Operating temperature (T-T)	-5 - 40 °C
Operating relative humidity (H-H)	10 - 90%
Other features
Compliance certificates	CE, Federal Communications Commission (FCC), Industry Canada (IC), National Defense Authorization Act (NDAA)

Desktop, 2x 3.5" drive bays, 2.5 GbE RJ45 (2.5G/1G/100M/10M), 5 Gbps USB-C, PoE++, Quad-Core ARM Cortex-A55 at 1.7 GHz, Bluetooth 4.1, 1.47" color LCM

Description

UniFi Network Attached Storage with (2) 3.5" HDD bays, 2.5 GbE networking, USB-C connectivity, and an included PoE++ adapter, all in a compact footprint.

Specifications

Storage
Storage drives installed	No
Installed storage drive type	No
Supported storage drive types	HDD
Number of storage drives supported	2
Storage drive size	3.5"
RAID support	Yes
RAID levels	1
Hot-swap drive bays	No
Storage drive sizes supported	3.5"
Processor
Processor manufacturer	ARM
Processor architecture	ARM Cortex-A57
Processor family	Cortex-A
Processor model	Cortex-A57
Processor frequency	1.7 GHz
Processor cores	4
Memory
Internal memory	4 GB
Network
Ethernet LAN	Yes
Ethernet LAN data rates	10,100,1000,2500 Mbit/s
Ports & interfaces
USB port	Yes
Ethernet LAN (RJ-45) ports	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	1
Design
Chassis type	Desktop
Product colour	White
Housing material	Polycarbonate (PC)
LED indicators	Status, System
Built-in display	Yes
Display type	LCM
Performance
Type	NAS
Backup function	Yes
Web-based management	Yes
Reset button	Yes
Other operating systems supported	Android, iOS
Software
Other operating systems supported	Android, iOS
Power
Power consumption (max)	60 W
Power supply location	External
Weight & dimensions
Width	129 mm
Depth	135 mm
Height	223.7 mm
Weight	1.3 kg
Technical details
Compliance certificates	CE, Federal Communications Commission (FCC), Industry Canada (IC), National Defense Authorization Act (NDAA)
Packaging content
External power adapter	Yes
Cables included	Power
Power cables quantity	1
Operational conditions
Operating temperature (T-T)	-5 - 40 °C
Operating relative humidity (H-H)	10 - 90%
Other features
Compliance certificates	CE, Federal Communications Commission (FCC), Industry Canada (IC), National Defense Authorization Act (NDAA)

Desktop, 4x 2.5/3.5" drive bays, 2x M.2 NVMe SSD bays, 2.5 GbE RJ45 (2.5G/1G/100M/10M), 5 Gbps USB-C, PoE+++, Quad-Core ARM Cortex-A55 at 1.7 GHz, Bluetooth 4.1, 1.47" color LCM

Description

UniFi Network Attached Storage with (4) 2.5/3.5" HDD bays, (2) M.2 NVMe SSD cache slots, 2.5 GbE networking, USB-C connectivity, and an included PoE+++ adapter, all in a compact footprint.

Specifications

Storage
NVMe	Yes
Storage drives installed	No
Installed storage drive type	No
Supported storage drive types	HDD & SSD
Number of storage drives supported	4
Storage drive size	2.5/3.5"
Storage drive sizes supported	2.5,3.5"
Number of M.2 (M & B) slots	2
Processor
Processor manufacturer	ARM
Processor architecture	ARM Cortex-A57
Processor family	Cortex-A
Processor model	Cortex-A57
Processor frequency	1.7 GHz
Processor cores	4
Memory
Internal memory	4 GB
Network
Ethernet LAN	Yes
Ethernet LAN data rates	10,100,1000,2500 Mbit/s
Ports & interfaces
USB port	Yes
Ethernet LAN (RJ-45) ports	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	1
Design
Chassis type	Desktop
Product colour	White
Housing material	Polycarbonate (PC)
LED indicators	Status, System
Built-in display	Yes
Display type	LCM
Performance
Type	NAS
Backup function	Yes
Web-based management	Yes
Power
Power consumption (max)	90 W
Power supply location	External
Weight & dimensions
Width	129 mm
Depth	246 mm
Height	224.5 mm
Weight	2.6 kg
Technical details
Compliance certificates	CE, Federal Communications Commission (FCC), Industry Canada (IC), National Defense Authorization Act (NDAA)
Packaging content
External power adapter	Yes
Cables included	Power
Power cables quantity	1
Operational conditions
Operating temperature (T-T)	-5 - 40 °C
Operating relative humidity (H-H)	10 - 90%
Other features
Compliance certificates	CE, Federal Communications Commission (FCC), Industry Canada (IC), National Defense Authorization Act (NDAA)

Quad-Core ARM Cortex-A57 at 1.7 GHz, 8 GB, 2U, 7x (7) 2.5/3.5" HDD / SSD, 10G SFP+, GbE RJ4, 1.3" touchscreen

Key Features

• (7) 2.5/3.5" HDD / SSD support
• (1) 10G SFP+ uplink and (1) GbE RJ45 port
• Data protection with RAID storage technology
• UniFi Power Backup ready
• 1.3" touchscreen for management

Description

2U rack-mount NAS with (7) 2.5/3.5" drive bays and 10 Gbps performance designed for large-scale file storage and sharing.

Specifications

Storage
Storage drives installed	No
Installed storage drive type	No
Supported storage drive types	HDD & SSD
Number of storage drives supported	7
RAID support	Yes
Storage drive sizes supported	2.5,3.5"
Processor
Processor manufacturer	ARM
Processor architecture	ARM Cortex-A57
Processor family	Cortex-A
Processor model	Cortex-A57
Processor frequency	1.7 GHz
Processor cores	4
Memory
Internal memory	8 GB
Network
Ethernet LAN	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s
Ports & interfaces
USB port	No
Ethernet LAN (RJ-45) ports	1
Fiber ports quantity	1
Fiber optic connector	SFP+
Design
Chassis type	Rack (2U)
Product colour	Grey
Cooling type	Active
Housing material	Steel
Number of fans	2 fan(s)
LED indicators	Status
Built-in display	Yes
Display type	LCM
Performance
Type	NAS
Backup function	Yes
Reset button	Yes
Power
Power consumption (max)	160 W
Power supply location	Built-in
Power supply unit (PSU) capacity	200 W
Redundant power supply (RPS) support	Yes
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Weight & dimensions
Width	442 mm
Depth	325 mm
Height	87 mm
Weight	9.2 kg
Technical details
Compliance certificates	CE, Federal Communications Commission (FCC), Industry Canada (IC)
Packaging content
Rack mount kit	Yes
Cables included	Power
Operational conditions
Operating temperature (T-T)	-5 - 40 °C
Operating relative humidity (H-H)	5 - 95%
Other features
Compliance certificates	CE, Federal Communications Commission (FCC), Industry Canada (IC)

Ubiquiti UniFi UNAS-Pro-4 4-Bay NAS Enclosure

Description

Ubiquiti UNAS Pro 4

SKU : UNAS-Pro-4

Tech Specs: Click Here

Description:
1U rack-mount NAS with (4) 2.5/3.5' HDD bays and (2) M.2 NVMe SSD cache slots, delivering faster access, lower latency, and high-availability 10 Gbps networking for large-scale file storage and sharing.

Specifications

Storage
Storage drives installed	No
Installed storage drive type	No
Supported storage drive types	HDD & SSD
Number of storage drives supported	6
RAID support	Yes
Storage drive sizes supported	2.5,3.5"
Processor
Processor manufacturer	ARM
Processor architecture	ARM Cortex-A57
Processor family	Cortex-A
Processor model	Cortex-A57
Processor frequency	1.7 GHz
Processor cores	4
Memory
Internal memory	16 GB
Network
Ethernet LAN	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s
Ports & interfaces
USB port	Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
Ethernet LAN (RJ-45) ports	1
Fiber optic connector	SFP+
Design
Chassis type	Rack (1U)
Product colour	Grey
Cooling type	Active
Housing material	SGCC
Performance
Type	NAS
Backup function	Yes
Power
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Weight & dimensions
Width	442.4 mm
Depth	400 mm
Height	43.7 mm
Weight	6.7 kg
Operational conditions
Operating temperature (T-T)	-5 - 40 °C
Operating relative humidity (H-H)	5 - 95%
