Intel Celeron N5105, 4GB DDR4, 2.5-Gigabit Ethernet, HDMI 2.0b, 22.9W, 18.6d, 1.71 kg

Key Features

• Quad-Core 10 nm Intel Celeron N5105 CPU
• 4x M.2 slots for NVMe SSDs
• 4 GB of DDR4-2933 RAM
• Dual 2.5-Gigabit Ethernet ports
• 3x USB 3.2 Gen 2 at 10 Gbps
• HDMI 2.0b
• Aesthetically pleasing M.2 SSD heat dissipation thermal vents
• Enjoy, download, upload and stream content with 4K transcoding
• Supports Wake on LAN and Wake on WAN

Description

The Best NAS 4 Flash
Hard Drives + Flash SSDs = The best of both worlds

Packed Full of Value

Intel’s all-new N5105 10 nm Quad-Core Celeron SoC at 2.0 GHz. With a boost frequency of up to 2.9 GHz, the powerful performance of the CPU ensures that working with the NAS is as smooth as butter while remaining affordable.

Upgradeable 4GB DDR4-2933 RAM

The AS54 comes with four Gigabytes of DDR4 RAM and can be upgraded up to 16GB. DDR4 RAM provides up to 30% greater performance than DDR3 while also lowering energy requirements by 40%.

End of the Road…for Gigabit Ethernet

2.5GbE is not the future. It’s now. With 2.5GbE ubiquitous on enthusiast motherboards and available as an affordable USB adapter, the ubiquity of 2.5GbE makes all transfers fast. Break barriers even further by combining the dual 2.5-Gigabit Ethernet ports in SMB Multichannel to enjoy speeds exceeding 2.5 Gbps.

SMB Multichannel (RAID 1)

Windows sequential read and write

* Performance figures are achieved in the ASUSTOR lab using state of the art client computers under optimized network settings, and could vary in different environments. Ordinary desktop or notebook computers may be unable to reproduce these figures.

Best 4 Flash

The AS54 series is equipped with four M.2 slots for NVMe SSDs to accelerate tasks that require high random IO performance to save unbelievable amounts of time in applications that can take advantage of SSDs, such as content creation. Each M.2 slot for NVMe SSDs is tool-free for easier installation while the cooling vents ensure SSDs run at optimum performance.

All New Gaming-Inspired Theme for ADM　

Take a look at the all new gaming-inspired elements brought to ADM.

USB 3.2 Gen 2 – Double Performance

The AS54 series upgrades the USB interface to USB 3.2 Gen 2x1. This means that the USB ports are up to twice the speed of the USB ports found on the previous generation of NAS devices at 10 Gbps. Plug in multiple expansion devices for extra storage or utilize the USB ports for backups and other peripherals for a truly custom experience.

Gaming-inspired looks

- Aesthetic cooling vents:
Ensuring high-speed transmission of data on M.2 SSD while looking good.

- Tool-free hard drives and SSDs:
Quickly install or replace hard drives and SSDs without tools.

- Magnetic panel:
Dust resistant to ensure extra longevity of hard drives and internal components.

Store Games on an iSCSI Drive

A NAS’s enormous capacity helps expand storage for a PC. According to modern operating systems, iSCSI drives appear as local drives and programs which cannot be installed on network shares may be installed. This enables certain games to be played from a NAS when they can’t be run on a network share.

ASUSTOR Live

Your own streaming center. Stream your from a phone or tablet as well as a computer to multiple streaming platforms, Including, but not limited to Twitch, YouTube, Facebook, Instagram, Restream or RTMP compatible platforms. Unlike services like restream.io, ASUSTOR Live doesn’t require fees to operate to stream to multiple platforms and channels which saves you money and streaming resources. Recordings can be safely saved to your NAS for future use.

Overwhelming 4K HDR Experience

The AS5402T features HDMI 2.0b with 10bit 4K hardware decoding, HEVC decoding and VP9 10bit Profile2 decoding for a smoother experience and lower CPU usage. Use Plex Pass or a third-party player to play 4K HDR videos.

Exclusive MyArchive Cold Backup Technology
Unlimited Capacity Expansion

MyArchive cold backup technology turns NAS hard disks into removable storage archives. Directly insert a MyArchive hard disk into the NAS to easily access, backup and share terabytes of content.

Protected From the Inside and Out

Protect your data from loss, damage and attacks with the ASUSTOR NAS. An ASUSTOR NAS is better protected by running the Linux-based ADM, employing a built-in firewall, ClamAV Antivirus, MyArchive and ADM’s various backup tools help protect ransomware even better.

Snapshot Center

Snapshot Center is a new feature for ASUSTOR NAS devices to utilize Btrfs and iSCSI volumes to take snapshots of the information inside a NAS. Snapshot Center supports up to 256 snapshots of a volume and can be done every five minutes, creating a backup that can be restored easily if data is damaged or lost.
MyArchive now supports Btrfs and snapshots. Btrfs for MyArchive supports snapshots and version history to help protect against accidental deletions or modifications.

DataSync Center

DataSync Center combines multiple cloud services into a single app. DataSync Center includes, but is not limited to Google Drive, Dropbox, OneDrive and Yandex and supports multitasking as well as multiple accounts. Control your data with instant and scheduled backups as well as using Cloud Backup Center to create a hybrid cloud that keeps your data online and offline, keeping your data protected.

Cloud Backup Center

Cloud Backup Center brings support for various business cloud services including, but not limited to Amazon S3, Backblaze B2, Baidu Cloud, IBM Cloud, Rackspace Cloud Files, Microsoft Azure Blob Storage, Alibaba Cloud, Google Cloud Storage, Box, hicloud S3, Lyve Cloud, SFTP and WebDAV. Control your data with instant and scheduled backups as well as using Cloud Backup Center to create a hybrid cloud that keeps your data online and offline, keeping your data protected.

Create the Ultimate Home Multimedia Center

Enjoy electrifying digital entertainment on demand with ASUSTOR NAS. Through ASUSTOR's App Central, you can install additional multimedia server Apps such as UPnP Media Server and OwnTone giving your NAS the ability to stream multimedia content to your computers, TVs and mobile devices.

Photo Gallery 3 + AiFoto 3

The all new Photo Gallery 3 and AiFoto 3 have been revamped and brings a variety of new features to make photo organization easier than ever. New features for Photo Gallery 3 include, but not are limited to custom folder selection, timelines, smart albums, deduplication, and new photo modes. Easily blow up photos to up to twice their size, play songs on slideshows, and customized share links make for an even better photo viewing and sharing experience.

Comprehensive Surveillance System

An ASUSTOR NAS provides optimal reliability for home and small business users looking to set up a surveillance system. Four free camera channels are offered, making it an extremely cost-effective surveillance solution for those looking to protect their home or small business. ASUSTOR provides each NAS with the capability to expand to more cameras for those with bigger demands. Up to 44 camera channels can be purchased through camera licenses. After installing Surveillance Center and its corresponding mobile app AiSecure, stream live surveillance feeds to virtually any internet-connected Android or iOS smartphone to keep an eye on your most valued assets from anywhere, inside or outside.

Portainer – Easy Docker Deployments

Even more possibilities for ADM with Portainer for Docker images. With thousands of images, Portainer can download and deploy more types of programs than ever before. Portainer is incredibly user friendly and employs a graphical interface to make docker images easier to deploy than ever.

Dr. ASUSTOR

ASUSTOR provides a holistic solution for protecting your data against a variety of threats using Dr. ASUSTOR. Dr. ASUSTOR helps protect your data from a variety of threats, including, but not limited to ransomware attacks.

Mobile Apps

ASUSTOR’s exclusive EZ Connect technology allows you to connect to your NAS from anywhere with your Mobile device in order to access and share your files. ASUSTOR mobile apps provide pass code lock functions in order to protect your privacy and data. You can also make use of HTTPS connections for even more added security.

App Central

Unleash the unlimited potential of ASUSTOR NAS. The applications that come pre-installed with each ASUSTOR NAS device are just the beginning. At your convenience, you can browse through and download any applications that pique your interest from App Central. Whether your interests lie in business, website construction or even digital home entertainment, App Central has got you covered. With over 200 unique Apps, App Central provides you with the boundless variety of applications that you require to satisfy your digital lifestyle needs. Explore the unlimited potential of ASUSTOR NAS devices while creating a personalized NAS device for yourself.

First-Class Product Warranty

All ASUSTOR NAS products come with a 3-year warranty. ASUSTOR continues to make customer service a priority in providing the highest standard of after-sales service and technical support.

Specifications

Storage
Total installed storage capacity	0 TB
Storage drives installed	No
Installed storage drive type	No
Number of storage drives installed	0
Supported storage drive types	HDD & SSD
Number of storage drives supported	14
Storage drive interface	M.2, Serial ATA III
Storage drive capacity	0 GB
Storage drive size	2.5/3.5"
RAID support	Yes
RAID levels	0, 1, 5, 6, 10
Hot-swap drive bays	Yes
Supported file systems	BTRFS, FAT32, HFS+, NTFS, exFAT, ext3, ext4
Processor
Processor manufacturer	Intel
Processor family	Intel® Celeron®
CPU configuration (max)	1
Processor threads	4
Processor cache	4 MB
Processor boost frequency	2.9 GHz
Processor model	N5105
Processor frequency	2 GHz
Processor cores	4
Memory
Internal memory type	DDR4
Internal memory	4 GB
Memory clock speed	2933 MHz
Maximum RAM supported	16 GB
Memory slots	2
Flash memory	8192 MB
Memory form factor	SO-DIMM
Network
Ethernet LAN	Yes
Ethernet LAN data rates	10,100,1000,2500 Mbit/s
Wake-on-LAN ready	Yes
Supported network protocols	CIFS / SMB, SMB 2.0 / 3.0, AFP, NFS, FTP (Unicode Supported), TFTP, WebDAV, Rsync, SSH, SFTP, iSCSI/IP-SAN, HTTP, HTTPS, Proxy, SNMP, Syslog
Ports & interfaces
USB port	Yes
HDMI version	2.0b
Ethernet LAN (RJ-45) ports	2
HDMI ports quantity	1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	3
Design
Product colour	Black
Cooling type	Active
Number of fans	1 fan(s)
Fan diameter	7 cm
Performance
System log	Yes
Share folder	Yes
Browser supported	FireFox, Chrome, Safari, Microsoft Edge
Type	NAS
Device class	Home & Home Office
Backup function	Yes
Backup features	Cloud
Number of users	4096 user(s)
Noise level	18.6 dB
Operating system installed	ADM
Operating system version	4.1
Security algorithms	256-bit AES
Access Control List (ACL)	Yes
Windows operating systems supported	Windows 10, Windows 11, Windows 7, Windows 8, Windows Vista, Windows XP
Linux operating systems supported	Yes
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.7.5 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks, Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura
Server operating systems supported	Windows Server 2003, Windows Server 2008, Windows Server 2012, Windows Server 2016, Windows Server 2019, Windows Server 2022
Software
Operating system installed	ADM
Operating system version	4.1
Windows operating systems supported	Windows 10, Windows 11, Windows 7, Windows 8, Windows Vista, Windows XP
Linux operating systems supported	Yes
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.7.5 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks, Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura
Server operating systems supported	Windows Server 2003, Windows Server 2008, Windows Server 2012, Windows Server 2016, Windows Server 2019, Windows Server 2022
Power
Power consumption (typical)	22.9 W
Power consumption (sleep)	0.71 W
AC input voltage	100 - 240 V
Weight & dimensions
Width	114 mm
Depth	230 mm
Height	170 mm
Weight	1.71 kg
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95%
Certificates
Certification	FCC, CE, VCCI, BSMI, C-TICK, KCC, BIS, CCC, UKCA
Other features
Certification	FCC, CE, VCCI, BSMI, C-TICK, KCC, BIS, CCC, UKCA

Intel Celeron N5105, 4GB DDR4, 2.5-Gigabit Ethernet, HDMI 2.0b, 38.3W

Key Features

• Quad-Core 10 nm Intel Celeron N5105 CPU
• 4x M.2 slots for NVMe SSDs
• 4 GB of DDR4-2933 RAM
• Dual 2.5-Gigabit Ethernet ports
• 3x USB 3.2 Gen 2 at 10 Gbps
• HDMI 2.0b
• Aesthetically pleasing M.2 SSD heat dissipation thermal vents
• Enjoy, download, upload and stream content with 4K transcoding
• Supports Wake on LAN and Wake on WAN

Description

The Best NAS 4 Flash
Hard Drives + Flash SSDs = The best of both worlds

Packed Full of Value

Intel’s all-new N5105 10 nm Quad-Core Celeron SoC at 2.0 GHz. With a boost frequency of up to 2.9 GHz, the powerful performance of the CPU ensures that working with the NAS is as smooth as butter while remaining affordable.

Upgradeable 4GB DDR4-2933 RAM

The AS54 comes with four Gigabytes of DDR4 RAM and can be upgraded up to 16GB. DDR4 RAM provides up to 30% greater performance than DDR3 while also lowering energy requirements by 40%.

End of the Road…for Gigabit Ethernet

2.5GbE is not the future. It’s now. With 2.5GbE ubiquitous on enthusiast motherboards and available as an affordable USB adapter, the ubiquity of 2.5GbE makes all transfers fast. Break barriers even further by combining the dual 2.5-Gigabit Ethernet ports in SMB Multichannel to enjoy speeds exceeding 2.5 Gbps.

SMB Multichannel (RAID 5)

Windows sequential read and write

* Performance figures are achieved in the ASUSTOR lab using state of the art client computers under optimized network settings, and could vary in different environments. Ordinary desktop or notebook computers may be unable to reproduce these figures.

Best 4 Flash

The AS54 series is equipped with four M.2 slots for NVMe SSDs to accelerate tasks that require high random IO performance to save unbelievable amounts of time in applications that can take advantage of SSDs, such as content creation. Each M.2 slot for NVMe SSDs is tool-free for easier installation while the cooling vents ensure SSDs run at optimum performance.

All New Gaming-Inspired Theme for ADM　

Take a look at the all new gaming-inspired elements brought to ADM.

USB 3.2 Gen 2 – Double Performance

The AS54 series upgrades the USB interface to USB 3.2 Gen 2x1. This means that the USB ports are up to twice the speed of the USB ports found on the previous generation of NAS devices at 10 Gbps. Plug in multiple expansion devices for extra storage or utilize the USB ports for backups and other peripherals for a truly custom experience.

Gaming-inspired looks

- Aesthetic cooling vents:
Ensuring high-speed transmission of data on M.2 SSD while looking good.

- Tool-free hard drives and SSDs:
Quickly install or replace hard drives and SSDs without tools.

- Magnetic panel:
Dust resistant to ensure extra longevity of hard drives and internal components.

Store Games on an iSCSI Drive

A NAS’s enormous capacity helps expand storage for a PC. According to modern operating systems, iSCSI drives appear as local drives and programs which cannot be installed on network shares may be installed. This enables certain games to be played from a NAS when they can’t be run on a network share.

ASUSTOR Live

Your own streaming center. Stream your from a phone or tablet as well as a computer to multiple streaming platforms, Including, but not limited to Twitch, YouTube, Facebook, Instagram, Restream or RTMP compatible platforms. Unlike services like restream.io, ASUSTOR Live doesn’t require fees to operate to stream to multiple platforms and channels which saves you money and streaming resources. Recordings can be safely saved to your NAS for future use.

Overwhelming 4K HDR Experience

The AS5404T features HDMI 2.0b with 10bit 4K hardware decoding, HEVC decoding and VP9 10bit Profile2 decoding for a smoother experience and lower CPU usage. Use Plex Pass or a third-party player to play 4K HDR videos.

Exclusive MyArchive Cold Backup Technology
Unlimited Capacity Expansion

MyArchive cold backup technology turns NAS hard disks into removable storage archives. Directly insert a MyArchive hard disk into the NAS to easily access, backup and share terabytes of content.

Protected From the Inside and Out

Protect your data from loss, damage and attacks with the ASUSTOR NAS. An ASUSTOR NAS is better protected by running the Linux-based ADM, employing a built-in firewall, ClamAV Antivirus, MyArchive and ADM’s various backup tools help protect ransomware even better.

Snapshot Center

Snapshot Center is a new feature for ASUSTOR NAS devices to utilize Btrfs and iSCSI volumes to take snapshots of the information inside a NAS. Snapshot Center supports up to 256 snapshots of a volume and can be done every five minutes, creating a backup that can be restored easily if data is damaged or lost.
MyArchive now supports Btrfs and snapshots. Btrfs for MyArchive supports snapshots and version history to help protect against accidental deletions or modifications.

DataSync Center

DataSync Center combines multiple cloud services into a single app. DataSync Center includes, but is not limited to Google Drive, Dropbox, OneDrive and Yandex and supports multitasking as well as multiple accounts. Control your data with instant and scheduled backups as well as using Cloud Backup Center to create a hybrid cloud that keeps your data online and offline, keeping your data protected.

Cloud Backup Center

Cloud Backup Center brings support for various business cloud services including, but not limited to Amazon S3, Backblaze B2, Baidu Cloud, IBM Cloud, Rackspace Cloud Files, Microsoft Azure Blob Storage, Alibaba Cloud, Google Cloud Storage, Box, hicloud S3, Lyve Cloud, SFTP and WebDAV. Control your data with instant and scheduled backups as well as using Cloud Backup Center to create a hybrid cloud that keeps your data online and offline, keeping your data protected.

Create the Ultimate Home Multimedia Center

Enjoy electrifying digital entertainment on demand with ASUSTOR NAS. Through ASUSTOR's App Central, you can install additional multimedia server Apps such as UPnP Media Server and OwnTone giving your NAS the ability to stream multimedia content to your computers, TVs and mobile devices.

Photo Gallery 3 + AiFoto 3

The all new Photo Gallery 3 and AiFoto 3 have been revamped and brings a variety of new features to make photo organization easier than ever. New features for Photo Gallery 3 include, but not are limited to custom folder selection, timelines, smart albums, deduplication, and new photo modes. Easily blow up photos to up to twice their size, play songs on slideshows, and customized share links make for an even better photo viewing and sharing experience.

Comprehensive Surveillance System

An ASUSTOR NAS provides optimal reliability for home and small business users looking to set up a surveillance system. Four free camera channels are offered, making it an extremely cost-effective surveillance solution for those looking to protect their home or small business. ASUSTOR provides each NAS with the capability to expand to more cameras for those with bigger demands. Up to 44 camera channels can be purchased through camera licenses. After installing Surveillance Center and its corresponding mobile app AiSecure, stream live surveillance feeds to virtually any internet-connected Android or iOS smartphone to keep an eye on your most valued assets from anywhere, inside or outside.

Portainer – Easy Docker Deployments

Even more possibilities for ADM with Portainer for Docker images. With thousands of images, Portainer can download and deploy more types of programs than ever before. Portainer is incredibly user friendly and employs a graphical interface to make docker images easier to deploy than ever.

Dr. ASUSTOR

ASUSTOR provides a holistic solution for protecting your data against a variety of threats using Dr. ASUSTOR. Dr. ASUSTOR helps protect your data from a variety of threats, including, but not limited to ransomware attacks.

Mobile Apps

ASUSTOR’s exclusive EZ Connect technology allows you to connect to your NAS from anywhere with your Mobile device in order to access and share your files. ASUSTOR mobile apps provide pass code lock functions in order to protect your privacy and data. You can also make use of HTTPS connections for even more added security.

App Central

Unleash the unlimited potential of ASUSTOR NAS. The applications that come pre-installed with each ASUSTOR NAS device are just the beginning. At your convenience, you can browse through and download any applications that pique your interest from App Central. Whether your interests lie in business, website construction or even digital home entertainment, App Central has got you covered. With over 200 unique Apps, App Central provides you with the boundless variety of applications that you require to satisfy your digital lifestyle needs. Explore the unlimited potential of ASUSTOR NAS devices while creating a personalized NAS device for yourself.

First-Class Product Warranty

All ASUSTOR NAS products come with a 3-year warranty. ASUSTOR continues to make customer service a priority in providing the highest standard of after-sales service and technical support.

Specifications

Storage
Total installed storage capacity	0 TB
Storage drives installed	No
Installed storage drive type	No
Number of storage drives installed	0
Supported storage drive types	HDD & SSD
Number of storage drives supported	16
Storage drive interface	M.2, Serial ATA III
Storage drive size	2.5/3.5"
RAID support	Yes
RAID levels	0, 1, 5, 6, 10
Hot-swap drive bays	Yes
Supported file systems	BTRFS, FAT32, HFS+, NTFS, exFAT, ext3, ext4
Processor
Processor manufacturer	Intel
Processor family	Intel® Celeron®
CPU configuration (max)	1
Processor threads	4
Processor cache	4 MB
Processor boost frequency	2.9 GHz
Processor model	N5105
Processor frequency	2 GHz
Processor cores	4
Memory
Internal memory type	DDR4
Internal memory	4 GB
Memory clock speed	2933 MHz
Maximum RAM supported	16 GB
Memory slots	2
Flash memory	8192 MB
Memory form factor	SO-DIMM
Network
Ethernet LAN	Yes
Ethernet LAN data rates	10,100,1000,2500 Mbit/s
Supported network protocols	CIFS / SMB, SMB 2.0 / 3.0, AFP, NFS, FTP (Unicode Supported), TFTP, WebDAV, Rsync, SSH, SFTP, iSCSI/IP-SAN, HTTP, HTTPS, Proxy, SNMP, Syslog
Ports & interfaces
USB port	Yes
HDMI version	2.0b
Ethernet LAN (RJ-45) ports	2
HDMI ports quantity	1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	3
Design
Product colour	Black
Cooling type	Active
Number of fans	1 fan(s)
Fan diameter	12 cm
Performance
System log	Yes
Share folder	Yes
Browser supported	FireFox, Chrome, Safari, Microsoft Edge
Type	NAS
Device class	Home & Home Office
Backup function	Yes
Backup features	Cloud
Number of users	4096 user(s)
Noise level	19.7 dB
Operating system installed	ADM
Operating system version	4.1
Security algorithms	256-bit AES
Access Control List (ACL)	Yes
Windows operating systems supported	Windows 10, Windows 11, Windows 7, Windows 8, Windows Vista, Windows XP
Linux operating systems supported	Yes
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.7.5 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks, Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura
Server operating systems supported	Windows Server 2003, Windows Server 2008, Windows Server 2012, Windows Server 2016, Windows Server 2019, Windows Server 2022
Software
Operating system installed	ADM
Operating system version	4.1
Windows operating systems supported	Windows 10, Windows 11, Windows 7, Windows 8, Windows Vista, Windows XP
Linux operating systems supported	Yes
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.7.5 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks, Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura
Server operating systems supported	Windows Server 2003, Windows Server 2008, Windows Server 2012, Windows Server 2016, Windows Server 2019, Windows Server 2022
Power
Power consumption (typical)	38.3 W
Power consumption (sleep)	0.81 W
AC input voltage	100 - 240 V
Weight & dimensions
Width	174 mm
Depth	230 mm
Height	170 mm
Weight	2.26 kg
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95%
Certificates
Certification	FCC, CE, VCCI, BSMI, C-TICK, KCC, BIS, CCC, UKCA
Other features
Certification	FCC, CE, VCCI, BSMI, C-TICK, KCC, BIS, CCC, UKCA

RTD1619B 1.7GHz quad-core, 2.5-Gigabit Ethernet, 2GB DDR4 RAM, ADM 4.1, USB, 13.1W, AES 256-Bit

Key Features

• Equipped with Realtek RTD1619B 1.7GHz quad-core processor
• Superfast 2.5-Gigabit Ethernet
• 2 GB DDR4 RAM
• Upgraded powerful internal display, smooth transcoding of 4K videos
• Supports Wake on LAN and Wake on WAN
• Btrfs/iSCSI Snapshots
• Tool-free installation

Description

Multimedia Transcoding - Btrfs Support - Maximum Value
Affordable personal cloud bringing high speeds for individuals and families.

CPU and iGPU Upgrades
The Drivestor Pro Gen2 contains a 1.7 GHz CPU, which is faster than the 1.4 GHz found in the first generation of Drivestor Pro NAS devices. The upgraded CPU also contains an upgraded iGPU that provides significant upgrades in transcoding features and performance, making the Drivestor Pro Gen2 the best price-performance NAS.

2.5-Gigabit Ethernet – Double Speed
The Drivestor 2 Pro Gen2, despite being extremely affordable contains 2.5-Gigabit Ethernet and more than doubles the performance of comparable Gigabit-class devices.

Regular access (RAID 1)

2GB DDR4 RAM
The Drivestor Pro Gen2 handles multitasking with ease by utilizing its 2 GB of DDR4 memory ensuring that virtually any task on an ASUSTOR NAS is executed smoothly.

Easily Get Started with ASUSTOR
The all-new navigation page helps make controlling your NAS and data even easier. A user friendly UI incentivizes becoming familiar with the numerous features an ASUSTOR NAS provides to ensure better data security.

Efficient and Powerful
The Drivestor Pro Gen2 are ASUSTOR’s highest value devices ever. Transcode 10-bit 4K H.265 media with hardware decoding easily that enables unbelievably smooth video playback in LooksGood.

Share and Share Alike!
Share links can create hyperlinks to share with other people to upload and download files to and from an ASUSTOR NAS. While share links come with multiple customizable options to increase convenience or security, people that use a share link are not required to have an account to upload and download files on the share link, making it more convenient for project collaboration or organizing travel photos.

Btrfs for ARM is Here!
The Drivestor Pro Gen2 is the first ARM NAS by ASUSTOR to support Btrfs. Use your Drivestor Pro Gen2 to create Btrfs snapshots in Snapshot Center for extra data protection. Snapshot Center supports scheduling or manual creation of snapshots, making it easier to restore files after unintentional modifications. Snapshots can be used to respond to ransomware threats in real time and help effectively protect data integrity.

Tool-free Installation
ASUSTOR’s Driverstor Pro Gen2 series introduces its new tool-free caddies as a way to simplify installation of hard drives. Each NAS comes included with brackets to install the drive easily. On the Driverstor Pro Gen2 series, hot-swapping of hard drives is supported, allowing you to change hard drives easily without powering down the NAS.

Exclusive MyArchive Cold Backup Technology
Unlimited Capacity Expansion
MyArchive cold storage technology turns NAS hard drives into removable storage archive drives. Directly insert a MyArchive hard drive into a free bay inside your NAS to easily access, backup and share terabytes of content.

Protected From the Inside and Out
Protect your data from loss, damage and attacks with the ASUSTOR NAS. An ASUSTOR NAS is better protected by running the Linux-based ADM, employing a built-in firewall, ClamAV Antivirus, MyArchive and ADM’s various backup tools help protect ransomware even better.

Network Attack Protection
- Firewall
- ADM Defender
- Cloud Backup Center offsite backups

Secure Data Transmission
- VPN connection
- SSL certificate connection
- Automatic logout

Internal Data
- MyArchive on and offsite backups
- AES-256 folder encryption
- Antivirus software

Access Control
- File/folder/app isolation
- 2-Step Verification
- Wake-on-LAN (WOL)
- Wake-on-WAN (WAN)

Protected From Ransomware
The Lockerstor comes with the most up-to-date version of ADM to help protect against ransomware attacks. With Snapshot Center and Btrfs providing efficient snapshots to easily restore lost data. Other security features found on the Lockerstor are the ability to create one or more replacement administrator accounts, a firewall by ADM Defender that features black and white lists and the ability to change default ports, disable SSH and Terminal to prevent remote attacks. MyArchive cold storage hard drive security can also be increased by implementing AES 256bit encryption.

DataSync Center
DataSync Center combines multiple cloud services into a single app. DataSync Center includes, but is not limited to Google Drive, Dropbox, OneDrive and Yandex and supports multitasking as well as multiple accounts. Control your data with instant and scheduled backups as well as using Cloud Backup Center to create a hybrid cloud that keeps your data online and offline, keeping your data protected.

Cloud Backup Center
Cloud Backup Center brings support for various business cloud services including, but not limited to Amazon S3, Backblaze B2, Baidu Cloud, IBM Cloud, Rackspace Cloud Files, Microsoft Azure Blob Storage, Alibaba Cloud, Google Cloud Storage, Box, hicloud S3, Lyve Cloud, SFTP and WebDAV. Control your data with instant and scheduled backups as well as using Cloud Backup Center to create a hybrid cloud that keeps your data online and offline, keeping your data protected.

Create the Ultimate Home Multimedia Center
Enjoy electrifying digital entertainment on demand with ASUSTOR NAS. Through ASUSTOR's App Central, you can install additional multimedia server Apps such as UPnP Media Server and OwnTone giving your NAS the ability to stream multimedia content to your computers, TVs and mobile devices.

Web Center
Easily set up a website with Web Center. Install Apache or Nginx or almost any other web server implementation and add multiple website portals for an easy-to-use web server experience.

Photo Gallery 3 + AiFoto 3
The all new Photo Gallery 3 and AiFoto 3 have been revamped and brings a variety of new features to make photo organization easier than ever. New features for Photo Gallery 3 include, but not are limited to custom folder selection, timelines, smart albums, deduplication, and new photo modes. Easily blow up photos to up to twice their size, play songs on slideshows, and customized share links make for an even better photo viewing and sharing experience.

Comprehensive Surveillance System
An ASUSTOR NAS provides optimal reliability for home and small business users looking to set up a surveillance system. Four free camera channels are offered, making it an extremely cost-effective surveillance solution for those looking to protect their home or small business. ASUSTOR provides each NAS with the capability to expand to more cameras for those with bigger demands. Up to 25 camera channels can be purchased through camera licenses. After installing Surveillance Center and its corresponding mobile app AiSecure, stream live surveillance feeds to virtually any internet-connected Android or iOS smartphone to keep an eye on your most valued assets from anywhere, inside or outside.

Portainer – Easy Docker Deployments
Even more possibilities for ADM with Portainer for Docker images. With thousands of images, Portainer can download and deploy more types of programs than ever before. Portainer is incredibly user friendly and employs a graphical interface to make docker images easier to deploy than ever.

Dr. ASUSTOR
ASUSTOR provides a holistic solution for protecting your data against a variety of threats using Dr. ASUSTOR. Dr. ASUSTOR helps protect your data from a variety of threats, including, but not limited to ransomware attacks.

Mobile Apps
ASUSTOR’s exclusive EZ Connect technology allows you to connect to your NAS from anywhere with your Mobile device in order to access and share your files. ASUSTOR mobile apps provide pass code lock functions in order to protect your privacy and data. You can also make use of HTTPS connections for even more added security.

App Central
Unleash the unlimited potential of ASUSTOR NAS. The applications that come pre-installed with each ASUSTOR NAS device are just the beginning. At your convenience, you can browse through and download any applications that pique your interest from App Central. Whether your interests lie in business, website construction or even digital home entertainment, App Central has got you covered. With over 200 unique Apps, App Central provides you with the boundless variety of applications that you require to satisfy your digital lifestyle needs. Explore the unlimited potential of ASUSTOR NAS devices while creating a personalized NAS device for yourself.

First-Class Product Warranty
All ASUSTOR NAS products come with a 3-year warranty. ASUSTOR continues to make customer service a priority in providing the highest standard of after-sales service and technical support.

Specifications

Storage
Supported storage drive types	HDD & SSD
Number of storage drives supported	2
Storage drive size	2.5/3.5"
RAID support	Yes
RAID levels	0, 1, 5, 6, 10, JBOD
Hot-swap drive bays	Yes
Supported file systems	BTRFS, FAT32, HFS+, NTFS, exFAT, ext3, ext4
Supported storage drive interfaces	Serial ATA III
Processor
Processor manufacturer	Realtek
Processor family	Realtek
Processor model	RTD1619B
Processor frequency	1.7 GHz
Processor cores	4
Memory
Internal memory type	DDR4
Internal memory	2 GB
Flash memory	8192 MB
Network
Ethernet LAN	Yes
Ethernet LAN data rates	100,1000,2500 Mbit/s
Jumbo frames support	Yes
iSCSI support	Yes
Wake-on-LAN ready	Yes
Supported network protocols	CIFS / SMB, SMB 2.0 / 3.0, AFP, NFS, FTP (Unicode Supported), TFTP, WebDAV, Rsync, SSH, SFTP, iSCSI/IP-SAN, HTTP, HTTPS, Proxy, SNMP, Syslog
Ports & interfaces
USB port	Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
Ethernet LAN (RJ-45) ports	1
Design
Product colour	Black
Cooling type	Active
Fan diameter	7 cm
LED indicators	Yes
Performance
Share folder access right management	Yes
Browser supported	Microsoft Edge, Firefox, Chrome
Type	NAS
Device class	Home & Home Office
Backup function	Yes
Backup features	Cloud
Number of users	4096 user(s)
Noise level (idle)	18.6 dB
Operating system installed	ADM
Operating system version	4.1
Web-based management	Yes
Security algorithms	256-bit AES, HTTPS, SSH, SSL/TLS
Access Control List (ACL)	Yes
Windows operating systems supported	Windows 10, Windows 11, Windows 7, Windows 8, Windows Vista, Windows XP
Linux operating systems supported	Yes
Mac operating systems supported	Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.7.5 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks, Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura
Server operating systems supported	Windows Server 2003, Windows Server 2008, Windows Server 2012, Windows Server 2016, Windows Server 2019, Windows Server 2022
Other operating systems supported	FreeBSD, UnixWare
Software
Operating system installed	ADM
Operating system version	4.1
Windows operating systems supported	Windows 10, Windows 11, Windows 7, Windows 8, Windows Vista, Windows XP
Linux operating systems supported	Yes
Mac operating systems supported	Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.7.5 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks, Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura
Server operating systems supported	Windows Server 2003, Windows Server 2008, Windows Server 2012, Windows Server 2016, Windows Server 2019, Windows Server 2022
Other operating systems supported	FreeBSD, UnixWare
Power
Power supply location	Built-in
Power supply unit (PSU) capacity	65 W
Number of power supply units	1
Power consumption (typical)	13.1 W
AC input voltage	100 - 240 V
Weight & dimensions
Width	114 mm
Depth	230 mm
Height	170 mm
Weight	1.6 kg
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95%
Certificates
Certification	FCC, CE, VCCI, BSMI, C-TICK, KCC, BIS, CCC
Other features
Certification	FCC, CE, VCCI, BSMI, C-TICK, KCC, BIS, CCC

2.5-Gigabit Ethernet, RTD1619B 1.7GHz quad-core, 2GB DDR4 RAM, 8GB eMMC, USB 3.2, 90W, 100 - 240V, 19.7dB, 2.2 kg

Key Features

• Equipped with Realtek RTD1619B 1.7GHz quad-core processor
• Superfast 2.5-Gigabit Ethernet
• 2 GB DDR4 RAM
• Upgraded powerful internal display, smooth transcoding of 4K videos
• Supports Wake on LAN and Wake on WAN
• Btrfs/iSCSI Snapshots
• Tool-free installation

Description

Multimedia Transcoding - Btrfs Support - Maximum Value
Affordable personal cloud bringing high speeds for individuals and families.

CPU and iGPU Upgrades
The Drivestor Pro Gen2 contains a 1.7 GHz CPU, which is faster than the 1.4 GHz found in the first generation of Drivestor Pro NAS devices. The upgraded CPU also contains an upgraded iGPU that provides significant upgrades in transcoding features and performance, making the Drivestor Pro Gen2 the best price-performance NAS.

2.5-Gigabit Ethernet – Double Speed
The Drivestor 4 Pro Gen2, despite being extremely affordable contains 2.5-Gigabit Ethernet and more than doubles the performance of comparable Gigabit-class devices.

Regular access (RAID 5)

2GB DDR4 RAM
The Drivestor Pro Gen2 handles multitasking with ease by utilizing its 2 GB of DDR4 memory ensuring that virtually any task on an ASUSTOR NAS is executed smoothly.

Easily Get Started with ASUSTOR
The all-new navigation page helps make controlling your NAS and data even easier. A user friendly UI incentivizes becoming familiar with the numerous features an ASUSTOR NAS provides to ensure better data security.

Efficient and Powerful
The Drivestor Pro Gen2 are ASUSTOR’s highest value devices ever. Transcode 10-bit 4K H.265 media with hardware decoding easily that enables unbelievably smooth video playback in LooksGood.

Share and Share Alike!
Share links can create hyperlinks to share with other people to upload and download files to and from an ASUSTOR NAS. While share links come with multiple customizable options to increase convenience or security, people that use a share link are not required to have an account to upload and download files on the share link, making it more convenient for project collaboration or organizing travel photos.

Btrfs for ARM is Here!
The Drivestor Pro Gen2 is the first ARM NAS by ASUSTOR to support Btrfs. Use your Drivestor Pro Gen2 to create Btrfs snapshots in Snapshot Center for extra data protection. Snapshot Center supports scheduling or manual creation of snapshots, making it easier to restore files after unintentional modifications. Snapshots can be used to respond to ransomware threats in real time and help effectively protect data integrity.

Tool-free Installation
ASUSTOR’s Driverstor Pro Gen2 series introduces its new tool-free caddies as a way to simplify installation of hard drives. Each NAS comes included with brackets to install the drive easily. On the Driverstor Pro Gen2 series, hot-swapping of hard drives is supported, allowing you to change hard drives easily without powering down the NAS.

Exclusive MyArchive Cold Backup Technology
Unlimited Capacity Expansion
MyArchive cold storage technology turns NAS hard drives into removable storage archive drives. Directly insert a MyArchive hard drive into a free bay inside your NAS to easily access, backup and share terabytes of content.

Protected From the Inside and Out
Protect your data from loss, damage and attacks with the ASUSTOR NAS. An ASUSTOR NAS is better protected by running the Linux-based ADM, employing a built-in firewall, ClamAV Antivirus, MyArchive and ADM’s various backup tools help protect ransomware even better.

Network Attack Protection
- Firewall
- ADM Defender
- Cloud Backup Center offsite backups

Secure Data Transmission
- VPN connection
- SSL certificate connection
- Automatic logout

Internal Data
- MyArchive on and offsite backups
- AES-256 folder encryption
- Antivirus software

Access Control
- File/folder/app isolation
- 2-Step Verification
- Wake-on-LAN (WOL)
- Wake-on-WAN (WAN)

Protected From Ransomware
The Lockerstor comes with the most up-to-date version of ADM to help protect against ransomware attacks. With Snapshot Center and Btrfs providing efficient snapshots to easily restore lost data. Other security features found on the Lockerstor are the ability to create one or more replacement administrator accounts, a firewall by ADM Defender that features black and white lists and the ability to change default ports, disable SSH and Terminal to prevent remote attacks. MyArchive cold storage hard drive security can also be increased by implementing AES 256bit encryption.

DataSync Center
DataSync Center combines multiple cloud services into a single app. DataSync Center includes, but is not limited to Google Drive, Dropbox, OneDrive and Yandex and supports multitasking as well as multiple accounts. Control your data with instant and scheduled backups as well as using Cloud Backup Center to create a hybrid cloud that keeps your data online and offline, keeping your data protected.

Cloud Backup Center
Cloud Backup Center brings support for various business cloud services including, but not limited to Amazon S3, Backblaze B2, Baidu Cloud, IBM Cloud, Rackspace Cloud Files, Microsoft Azure Blob Storage, Alibaba Cloud, Google Cloud Storage, Box, hicloud S3, Lyve Cloud, SFTP and WebDAV. Control your data with instant and scheduled backups as well as using Cloud Backup Center to create a hybrid cloud that keeps your data online and offline, keeping your data protected.

Cloud Backup Center
Cloud Backup Center brings support for various business cloud services including, but not limited to Amazon S3, Backblaze B2, Baidu Cloud, IBM Cloud, Rackspace Cloud Files, Microsoft Azure Blob Storage, Alibaba Cloud, Google Cloud Storage, Box, hicloud S3, Lyve Cloud, SFTP and WebDAV. Control your data with instant and scheduled backups as well as using Cloud Backup Center to create a hybrid cloud that keeps your data online and offline, keeping your data protected.

Web Center
Easily set up a website with Web Center. Install Apache or Nginx or almost any other web server implementation and add multiple website portals for an easy-to-use web server experience.

Photo Gallery 3 + AiFoto 3
The all new Photo Gallery 3 and AiFoto 3 have been revamped and brings a variety of new features to make photo organization easier than ever. New features for Photo Gallery 3 include, but not are limited to custom folder selection, timelines, smart albums, deduplication, and new photo modes. Easily blow up photos to up to twice their size, play songs on slideshows, and customized share links make for an even better photo viewing and sharing experience.

Comprehensive Surveillance System
An ASUSTOR NAS provides optimal reliability for home and small business users looking to set up a surveillance system. Four free camera channels are offered, making it an extremely cost-effective surveillance solution for those looking to protect their home or small business. ASUSTOR provides each NAS with the capability to expand to more cameras for those with bigger demands. Up to 25 camera channels can be purchased through camera licenses. After installing Surveillance Center and its corresponding mobile app AiSecure, stream live surveillance feeds to virtually any internet-connected Android or iOS smartphone to keep an eye on your most valued assets from anywhere, inside or outside.

Portainer – Easy Docker Deployments
Even more possibilities for ADM with Portainer for Docker images. With thousands of images, Portainer can download and deploy more types of programs than ever before. Portainer is incredibly user friendly and employs a graphical interface to make docker images easier to deploy than ever.

Dr. ASUSTOR
ASUSTOR provides a holistic solution for protecting your data against a variety of threats using Dr. ASUSTOR. Dr. ASUSTOR helps protect your data from a variety of threats, including, but not limited to ransomware attacks.

Mobile Apps
ASUSTOR’s exclusive EZ Connect technology allows you to connect to your NAS from anywhere with your Mobile device in order to access and share your files. ASUSTOR mobile apps provide pass code lock functions in order to protect your privacy and data. You can also make use of HTTPS connections for even more added security.

App Central
Unleash the unlimited potential of ASUSTOR NAS. The applications that come pre-installed with each ASUSTOR NAS device are just the beginning. At your convenience, you can browse through and download any applications that pique your interest from App Central. Whether your interests lie in business, website construction or even digital home entertainment, App Central has got you covered. With over 200 unique Apps, App Central provides you with the boundless variety of applications that you require to satisfy your digital lifestyle needs. Explore the unlimited potential of ASUSTOR NAS devices while creating a personalized NAS device for yourself.

First-Class Product Warranty

All ASUSTOR NAS products come with a 3-year warranty. ASUSTOR continues to make customer service a priority in providing the highest standard of after-sales service and technical support.

Specifications

Storage
Supported storage drive types	HDD & SSD
Number of storage drives supported	4
RAID support	Yes
RAID levels	0, 1, 5, 6, 10, JBOD
Hot-swap drive bays	Yes
Supported file systems	BTRFS, FAT32, HFS+, NTFS, exFAT, ext3, ext4
Supported storage drive interfaces	Serial ATA III
Storage drive sizes supported	2.5,3.5"
Processor
Processor manufacturer	Realtek
Processor family	Realtek
Processor model	RTD1619B
Processor frequency	1.7 GHz
Processor cores	4
Memory
Internal memory type	DDR4
Internal memory	2 GB
Flash memory	8192 MB
Network
Ethernet LAN	Yes
Ethernet LAN data rates	100,1000,2500 Mbit/s
Jumbo frames support	Yes
iSCSI support	Yes
Wake-on-LAN ready	Yes
Supported network protocols	CIFS / SMB, SMB 2.0 / 3.0, AFP, NFS, FTP (Unicode Supported), TFTP, WebDAV, Rsync, SSH, SFTP, iSCSI/IP-SAN, HTTP, HTTPS, Proxy, SNMP, Syslog
Ports & interfaces
USB port	Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
Ethernet LAN (RJ-45) ports	1
Design
Product colour	Black
Cooling type	Active
Number of fans	1 fan(s)
Fan diameter	12 cm
LED indicators	Yes
Performance
Built-in UPnP AV media server	Yes
Share folder access right management	Yes
Browser supported	Microsoft Edge, Firefox, Chrome
Type	NAS
Device class	Home & Home Office
Backup function	Yes
Backup features	Cloud
Number of users	4096 user(s)
Noise level (idle)	19.7 dB
Operating system installed	ADM
Operating system version	4.1
Web-based management	Yes
Security algorithms	256-bit AES, HTTPS, SSH, SSL/TLS
Access Control List (ACL)	Yes
Windows operating systems supported	Windows 10, Windows 11, Windows 7, Windows 8, Windows Vista, Windows XP
Linux operating systems supported	Yes
Mac operating systems supported	Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.7.5 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks, Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura
Server operating systems supported	Windows Server 2003, Windows Server 2008, Windows Server 2012, Windows Server 2016, Windows Server 2019, Windows Server 2022
Other operating systems supported	FreeBSD, UnixWare
Software
Operating system installed	ADM
Operating system version	4.1
Windows operating systems supported	Windows 10, Windows 11, Windows 7, Windows 8, Windows Vista, Windows XP
Linux operating systems supported	Yes
Mac operating systems supported	Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.7.5 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks, Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura
Server operating systems supported	Windows Server 2003, Windows Server 2008, Windows Server 2012, Windows Server 2016, Windows Server 2019, Windows Server 2022
Other operating systems supported	FreeBSD, UnixWare
Power
Power supply location	Built-in
Power supply unit (PSU) capacity	90 W
Number of power supply units	1
Power consumption (typical)	25.1 W
AC input voltage	100 - 240 V
Weight & dimensions
Width	174 mm
Depth	230 mm
Height	170 mm
Weight	2.2 kg
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95%
Certificates
Certification	FCC, CE, VCCI, BSMI, C-TICK, KCC, BIS, CCC
Other features
Certification	FCC, CE, VCCI, BSMI, C-TICK, KCC, BIS, CCC

Intel Celeron N5105, 4GB SO-DIMM DDR4, 65W x1, 8GB eMMC, 1x HDMI 2.0b, 17.7dB (HDD idle), 100V to 240V AC

Key Features

• Quad-Core 10 nm Intel Celeron N5105 CPU - 31% more performance over Gemini Lake
• Superfast 2.5-Gigabit Ethernet ports
• Flexible PCIe slot for M.2 SSDs
• Supports PCIe 3.0 SSDs for up to twice the performance of PCIe 2.0
• Uses DDR4-2933 with 40% more performance
• USB 3.2 Gen2 ports – 10Gbps speed
• Enjoy, download, upload and stream content with 4K transcoding
• Increased ventilation for SSDs
• Supports Wake on LAN and Wake on WAN

Description

Enthusiast-grade NAS with two, four or six bays
The LOCKERSTOR Gen2 series of NAS devices come with the all-new Quad-Core Intel Celeron N5105 CPU featuring Intel 10 nm technology. Intel’s Jasper Lake Celeron CPUs bring up to 31% extra performance over the previous generation of Celeron CPUs. The LOCKERSTOR Gen2 is flexible. Install up to four M.2 SSDs or a 10-Gigabit Ethernet card in the available PCI Express slot for maximum performance.
The LOCKERSTOR Gen2 uses DDR4-2933 and super-fast 2.5-Gigabit Ethernet which makes content creation even easier than ever before.

Unleashed Potential
Supports Premiere Pro & Final Cut Pro
Easily collaborate with anyone, anywhere.
Adobe Creative Cloud data backup and version control
Stream YouTube and/or Twitch videos with rebroadcasting and live recording functionality

CPU
Intel’s newest N5105 Quad-Core CPU comes with Intel 10 nm technology and up to 31% increased performance over Gemini Lake SoCs. The N5105 is clocked at 2.0 GHz with a boost of up to 2.9 GHz, enabling efficient content creation with the added flexibility of 10-Gigabit Ethernet upgrades.

Keeping Cool
With up to four SSDs, a considerable amount of heat can be generated. With extra ventilation, the Lockerstor Gen2 ensures that all components in your NAS receive cooling.

USB 3.2 Gen 2x1 – A First for ASUSTOR
The Lockerstor Gen2 series now support USB 3.2 Gen 2x1 for the first time on an ASUSTOR NAS. Enjoy up to double the performance compared with USB 3.2 Gen1 at up to 10 Gbps.

Four M.2 Slots
The Lockerstor Gen2 series of NAS devices come with four M.2 slots for caching or storage or both. Either use all slots for one purpose or mix and match depending on your needs.

Also Supports 10-Gigabit Ethernet
The PCIe slot in the Lockerstor Gen2 series is no longer proprietary and now accepts 10-Gigabit Ethernet cards for maximum flexibility.

Specifications

Storage
Total installed storage capacity	0 TB
Storage drives installed	No
Installed storage drive type	No
Number of storage drives installed	0
Supported storage drive types	HDD & SSD
Number of storage drives supported	2
Storage drive interface	M.2, Serial ATA
Storage drive capacity	0 GB
RAID support	Yes
Supported file systems	BTRFS, FAT32, HFS+, NTFS, exFAT, ext3, ext4
Storage drive sizes supported	2.5,3.5,M.2
Number of M.2 (M & B) slots	4
Processor
Processor manufacturer	Intel
Processor family	Intel® Celeron®
CPU configuration (max)	1
Processor cache	4 MB
On-board graphics card model	Intel® UHD Graphics
Processor model	N5105
Processor frequency	2 GHz
Processor cores	4
Memory
Internal memory type	DDR4
Internal memory	4 GB
Memory clock speed	2933 MHz
Maximum RAM supported	16 GB
Memory slots	2
Flash memory	8000 MB
Memory form factor	SO-DIMM
Network
Ethernet LAN	Yes
Dynamic DNS (DDNS)	Yes
Ethernet LAN data rates	100,1000,2500 Mbit/s
Jumbo frames support	Yes
iSCSI support	Yes
Wake-on-LAN ready	Yes
Supported network protocols	CIFS/SMB, SMB 2.0/3.0, AFP, NFS, FTP (Unicode Supported), TFTP, WebDAV, Rsync, SSH, SFTP, iSCSI/IP-SAN, HTTP, HTTPS, Proxy, SNMP, Syslog
Ports & interfaces
USB port	Yes
HDMI version	2.0b
Ethernet LAN (RJ-45) ports	2
HDMI ports quantity	1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	2
Graphics
On-board graphics card model	Intel® UHD Graphics
Design
Chassis type	Desktop
Product colour	Black
Cooling type	Active
Number of fans	1 fan(s)
Fan diameter	7 cm
LED indicators	Yes
Performance
System log	Yes
Type	NAS
Universal Plug and Play (UPnP)	Yes
Device class	Home & Home Office
Backup function	Yes
Backup features	Cloud
Number of users	4096 user(s)
Noise level (idle)	17.7 dB
Operating system installed	ADM
Operating system version	4.1 Onwards
Web-based management	Yes
Access Control List (ACL)	Yes
Windows operating systems supported	Windows 10, Windows 11, Windows 7, Windows 8, Windows Vista, Windows XP
Linux operating systems supported	Yes
Mac operating systems supported	Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks, Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey
Server operating systems supported	Windows Server 2003, Windows Server 2008, Windows Server 2012, Windows Server 2016, Windows Server 2019, Windows Server 2022
Software
Operating system installed	ADM
Operating system version	4.1 Onwards
Windows operating systems supported	Windows 10, Windows 11, Windows 7, Windows 8, Windows Vista, Windows XP
Linux operating systems supported	Yes
Mac operating systems supported	Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks, Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey
Server operating systems supported	Windows Server 2003, Windows Server 2008, Windows Server 2012, Windows Server 2016, Windows Server 2019, Windows Server 2022
Power
Power supply location	External
Power supply unit (PSU) capacity	65 W
Number of power supply units	1
Power consumption (typical)	21 W
Power consumption (sleep)	0.79 W
AC input voltage	100 - 240 V
Weight & dimensions
Width	163.5 mm
Depth	108 mm
Height	230 mm
Weight	2 kg
Technical details
Harmonized System (HS) code	84714100
Processor special features
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel Trusted Execution Technology	No
Intel 64	Yes
Idle States	Yes
Enhanced Intel SpeedStep Technology	Yes
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95%
Logistics data
Harmonized System (HS) code	84714100

Dual 5-Gigabit Ethernet, Quad-Core 10 nm Intel Celeron N5105 CPU

Key Features

• Quad-Core 10 nm Intel Celeron N5105 CPU
• Dual 5-Gigabit Ethernet ports
• 4x M.2 slots for NVMe SSDs
• 4 GB of DDR4-2933 RAM
• 2x USB 10Gbps
• Supports Wake on LAN and Wake on WAN

Description

Powered by the Latest 10 nm Intel Jasper Lake Celeron Quad-Core Processors
The Lockerstor Gen2/Gen2+ comes with Intel’s newest Quad-Core Celeron CPUs. The N5105 comes with Intel 10 nm technology and is up to 31% faster than Gemini Lake SoCs. The Celeron N5105 is clocked at 2.0 GHz with 2.9 GHz, enabling efficient content creation with the added flexibility of 10-Gigabit Ethernet upgrades.

* Lockerstor 2 Gen2/Gen2+ (AS6702T/AS6702T v2) 10GbE not supported.

Four M.2 Slots - Have Your Cake and Eat it Too
The Lockerstor Gen2+ series of NAS devices come with four M.2 slots for caching or storage or both. Either use all slots for one purpose or mix and match depending on your needs.

Four M.2 SSD slots bring a number of custom scenarios to your NAS when it comes to accelerating your storage.

Specifications

Storage
Storage drives installed	No
Installed storage drive type	No
Supported storage drive types	HDD & SSD
Number of storage drives supported	4
RAID support	Yes
RAID levels	0, 1, 5, 6, 10, JBOD
Supported file systems	BTRFS, FAT32, HFS+, NTFS, exFAT, ext3, ext4
Supported storage drive interfaces	M.2, Serial ATA
Storage drive sizes supported	2.5,3.5,M.2
Number of M.2 (M & B) slots	4
Processor
Processor manufacturer	Intel
Processor family	Intel® Celeron®
Processor threads	4
Processor boost frequency	2.9 GHz
On-board graphics card model	Intel® UHD Graphics
Processor model	N5105
Processor frequency	2 GHz
Processor cores	4
Memory
Internal memory type	DDR4
Internal memory	4 GB
Memory clock speed	2933 MHz
Maximum RAM supported	16 GB
Memory slots	2
Flash memory	8000 MB
Memory form factor	SO-DIMM
Network
Ethernet LAN	Yes
Dynamic DNS (DDNS)	Yes
Ethernet LAN data rates	100,1000,2500 Mbit/s
Jumbo frames support	Yes
iSCSI support	Yes
Wake-on-LAN ready	Yes
Supported network protocols	CIFS / SMB, SMB 2.0 / 3.0, AFP, NFS, FTP (Unicode Supported), TFTP, WebDAV, Rsync, SSH, SFTP, iSCSI/IP-SAN, HTTP, HTTPS, Proxy, SNMP, Syslog
Ports & interfaces
USB port	Yes
HDMI version	2.0b
Ethernet LAN (RJ-45) ports	2
HDMI ports quantity	1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	2
Concurrent connections	512
Graphics
On-board graphics card model	Intel® UHD Graphics
Design
Chassis type	Desktop
Product colour	Black
Cooling type	Active
Number of fans	1 fan(s)
Fan diameter	12 cm
LED indicators	Yes
Built-in display	Yes
Display type	LCD
Performance
System log	Yes
S.M.A.R.T. support	Yes
Browser supported	Firefox, Chrome, Safari, Microsoft Edge
Type	NAS
Universal Plug and Play (UPnP)	Yes
Device class	Home & Home Office
Backup function	Yes
Backup features	Cloud
Number of users	4096 user(s)
Noise level	17.6 dB
Operating system installed	ADM
Operating system version	4.1 Onwards
Web-based management	Yes
Access Control List (ACL)	Yes
Windows operating systems supported	Yes
Linux operating systems supported	Yes
Mac operating systems supported	Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks, Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey
Server operating systems supported	Windows Server 2003, Windows Server 2008, Windows Server 2012 Core, Windows Server 2016, Windows Server 2019, Windows Server 2022
Software
Operating system installed	ADM
Operating system version	4.1 Onwards
Windows operating systems supported	Yes
Linux operating systems supported	Yes
Mac operating systems supported	Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks, Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey
Server operating systems supported	Windows Server 2003, Windows Server 2008, Windows Server 2012 Core, Windows Server 2016, Windows Server 2019, Windows Server 2022
Power
Power supply location	External
Power supply unit (PSU) capacity	90 W
Power consumption (typical)	35 W
Power consumption (sleep)	0.88 W
AC input voltage	100 - 240 V
Weight & dimensions
Width	170 mm
Depth	230 mm
Height	185.5 mm
Weight	2.94 kg
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95%

Asustor LOCKERSTOR 4 Gen3, NAS, Desktop, AMD Ryzen, V3C14, 16 GB, DDR5

Description

Asustor LOCKERSTOR 4 Gen3. Type: NAS. Chassis type: Desktop. Device class: Home & Home Office. Processor family: AMD Ryzen, Processor model: V3C14, Processor frequency: 2.3 GHz. Internal memory: 16 GB, Internal memory type: DDR5. Operating system installed: ADM

Specifications

Storage
Storage drives installed	No
Installed storage drive type	No
Supported storage drive types	HDD & SSD
Number of storage drives supported	4
Storage drive interface	M.2
RAID support	Yes
RAID levels	0, 1, 5, 6, 10
Supported file systems	BTRFS, HFS+, NTFS, exFAT, ext4
Storage drive sizes supported	2.5,3.5,M.2
Processor
Processor manufacturer	AMD
Processor family	AMD Ryzen
Processor boost frequency	3.8 GHz
Processor model	V3C14
Processor frequency	2.3 GHz
Processor cores	4
Memory
Internal memory type	DDR5
Internal memory	16 GB
Memory clock speed	4800 MHz
Maximum RAM supported	64 GB
Memory slots	2
Flash memory	8000 MB
Memory form factor	SO-DIMM
Network
Ethernet LAN	Yes
Ethernet LAN data rates	100,1000,2500,10000 Mbit/s
Ports & interfaces
USB port	Yes
Ethernet LAN (RJ-45) ports	4
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	3
Design
Chassis type	Desktop
Product colour	Black
Cooling type	Active
Number of fans	1 fan(s)
Fan diameter	12 cm
Built-in display	Yes
Display type	LCD
Performance
Type	NAS
Device class	Home & Home Office
Backup function	Yes
Noise level	17.6 dB
Operating system installed	ADM
Web-based management	Yes
Access Control List (ACL)	Yes
Windows operating systems supported	Windows 10, Windows 11
Linux operating systems supported	Yes
Mac operating systems supported	Yes
Server operating systems supported	Windows Server 2016, Windows Server 2019, Windows Server 2022
Software
Operating system installed	ADM
Windows operating systems supported	Windows 10, Windows 11
Linux operating systems supported	Yes
Mac operating systems supported	Yes
Server operating systems supported	Windows Server 2016, Windows Server 2019, Windows Server 2022
Power
Power supply location	External
Power supply unit (PSU) capacity	90 W
Power consumption (typical)	34 W
Power consumption (sleep)	2.3 W
AC input voltage	100 - 240 V
Weight & dimensions
Width	170 mm
Depth	230 mm
Height	185.5 mm
Weight	3.2 kg
Technical details
Warranty period	3 year(s)
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95%
Storage temperature (T-T)	-20 - 70 °C
Storage relative humidity (H-H)	5 - 95%
Certificates
Certification	FCC, CE, VCCI, BSMI, C-TICK, KCC, BIS, CCC, UKCA
Other features
Certification	FCC, CE, VCCI, BSMI, C-TICK, KCC, BIS, CCC, UKCA
Warranty period	3 year(s)
