Shuttle XPC slim Barebone XB860G2 - S1851, Intel H860, 1xDP, 2xHDMI, 2 PCIe Slots (1x 16X & 1x X1), 2x Intel LAN (1G + 2.5G), 8x USB, 3x M.2, 24/7 permanent operation
Shuttle XPC slim Barebone XB860G2 - S1851, Intel H860, 1xDP, 2xHDMI, 2 PCIe Slots (1x 16X & 1x X1), 2x Intel LAN (1G + 2.5G), 8x USB, 3x M.2, 24/7 permanent operation
SKU: XB860G2
Availability:
Sale
Sold out
In Stock
10+ in stock
Regular price
$860.57
Price:
$860.57
Regular price
$866.40
Taxes included.
IN STOCK AT WAREHOUSE DELIVERY TO STORE 2-4 DAYS.
Couldn't load pickup availability
S1851, Intel H860, 1xDP, 2xHDMI, 2 PCIe Slots (1x 16X & 1x X1), 2x Intel LAN (1G + 2.5G), 8x USB, 3x M.2, 24/7 permanent operation
View full details
Description
The Shuttle XPC slim Barebone XB860G2 is a 4.5-litre PC with two slots for PCI-Express expansion cards. Together with a powerful socket LGA1851 Intel Core Ultra 2xx desktop processor (code name "Arrow Lake-S"), this platform is perfectly suited for many professional applications where performance, flexibility and a compact form factor matter. You can install e.g. a multiport graphics card, a video capture card or I/O card to set up a mini PC for applications such as video wall presentations, graphics workstations, media capturing, surveillance, POS, POI as well as network and industrial applications. Even mid-range gaming is possible.Specifications
| Motherboard | |
|---|---|
| Motherboard form factor | mini ITX |
| Processor socket | LGA 1851 (Socket V1) |
| Number of processors supported | 1 |
| Motherboard chipset | Intel B860 |
| Processor | |
| Built-in processor | No |
| Processor socket | LGA 1851 (Socket V1) |
| Number of processors supported | 1 |
| Motherboard chipset | Intel B860 |
| Memory | |
| Memory voltage | 1.1 V |
| Memory slots type | SO-DIMM |
| Number of memory slots | 2 |
| Supported memory types | DDR5-SDRAM |
| Supported memory clock speeds | 5600 MHz |
| Memory channels | Dual-channel |
| Maximum internal memory | 96 GB |
| Non-ECC | Yes |
| Internal memory installed | No |
| Video | |
| On-board graphics card | Yes |
| Storage | |
| Supported storage drive types | SSD |
| Storage drive sizes supported | M.2 |
| Storage drive interface | PCI Express |
| Number of storage drives supported | 3 |
| SSD form factor | M.2 |
| NVMe | Yes |
| Storage drives installed | No |
| Graphics | |
| On-board graphics card | Yes |
| Performance | |
| Motherboard form factor | mini ITX |
| Trusted Platform Module (TPM) version | 2.0 |
| Trusted Platform Module (TPM) | Yes |
| Processor socket | LGA 1851 (Socket V1) |
| Number of processors supported | 1 |
| Motherboard chipset | Intel B860 |
| BIOS type | UEFI AMI |
| Audio chip | Realtek ALC888S |
| Harmonized System (HS) code | 84733080 |
| Audio | |
| Built-in speaker(s) | No |
| Audio chip | Realtek ALC888S |
| Network | |
| Ethernet LAN | Yes |
| Wi-Fi | No |
| LAN controller | Intel I226-LM, Intel® I219-LM |
| Ports & interfaces | |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 3 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 |
| DisplayPort version | 1.4a |
| VGA (D-Sub) ports quantity | 0 |
| USB 2.0 ports quantity | 2 |
| Microphone in | Yes |
| Headphone outputs | 1 |
| HDMI version | 2.0/2.1 |
| HDMI ports quantity | 2 |
| Ethernet LAN (RJ-45) ports | 2 |
| DisplayPorts quantity | 1 |
| DC-in jack | Yes |
| Design | |
| VESA mounting | Yes |
| Motherboard form factor | mini ITX |
| Product type | PC barebone |
| Panel mounting interface | 75 x 75,100 x 100 mm |
| LED indicators | HDD, Power |
| Cooling type | Active |
| Product colour | Black |
| Chassis type | 3.5L sized PC |
| Cable lock slot type | Kensington |
| Cable lock slot | Yes |
| Colour | |
| Product colour | Black |
| Technical details | |
| Panel mounting interface | 75 x 75,100 x 100 mm |
| Trusted Platform Module (TPM) version | 2.0 |
| Trusted Platform Module (TPM) | Yes |
| Quick start guide | Yes |
| Cooling type | Active |
| Chassis type | 3.5L sized PC |
| Cable lock slot type | Kensington |
| Cable lock slot | Yes |
| BIOS type | UEFI AMI |
| Harmonized System (HS) code | 84733080 |
| Sustainability certificates | ErP, ENERGY STAR |
| Compliance certificates | UKCA, CE, Federal Communications Commission (FCC), BSMI, RCM, VCCI, RoHS |
| Packaging data | |
| Power cord included | Yes |
| Drivers included | Yes |
| AC adapter included | Yes |
| Package weight | 3.2 kg |
| Indication | |
| LED indicators | HDD, Power |
| Logistics data | |
| Harmonized System (HS) code | 84733080 |
| Sustainability | |
| Sustainability certificates | ErP, ENERGY STAR |
| Power | |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| AC adapter output voltage | 19.5 V |
| AC adapter output current | 9.23 A |
| Power supply type | External AC adapter |
| Power supply | 180 W |
| Number of power supply units | 1 |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 50 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Weight & dimensions | |
| Width | 238 mm |
| Depth | 200 mm |
| Height | 72.5 mm |
| Weight | 1.9 kg |
| Package weight | 3.2 kg |
| Packaging content | |
| Quick start guide | Yes |
| Power cord included | Yes |
| Drivers included | Yes |
| AC adapter included | Yes |
| Other features | |
| Chassis type | 3.5L sized PC |
