GIGABYTE Radeon RX 9060 XT GAMING OC 16G Graphics Card

16GB GDDR6, 128bit, PCI-E 5.0, 3320 MHz Core Clock, 2 x DisplayPort, 1 x HDMI, GV-R9060XTGAMING OC-16GD

Key Features

• Powered by Radeon RX 9060 XT
• Integrated with 16GB GDDR6 128bit memory interface
• WINDFORCE cooling system
• RGB Lighting
• Dual BIOS (Performance / Silent)
• Reinforced structure

Description

Experience the next level of gaming immersion with GIGABYTE's AMD graphics cards. Crafted to deliver uncompromising performance and stunning visuals, our GPUs redefine gaming excellence. Featuring advanced cooling solutions and innovative technologies, GIGABYTE AMD graphics cards empower gamers to push the boundaries of what's possible, delivering unmatched gaming experiences.

Specifications

Processor
Graphics processor	Radeon RX 9060 XT
Maximum resolution	7680 x 4320 pixels
Graphics processor family	AMD
CUDA	No
Processor boost clock speed	3320 MHz
Stream processors	2048
Parallel processing technology support	Not supported
Maximum displays per videocard	4
Processor boost clock speed (Gaming mode)	2780 MHz
Memory
Discrete graphics card memory	16 GB
Graphics card memory type	GDDR6
Memory bus	128 bit
Memory clock speed	20000 MHz
Data transfer rate	20 Gbit/s
Ports & interfaces
Interface type	PCI Express x16 5.0
HDMI ports quantity	1
DVI-I ports quantity	0
DVI-D ports quantity	0
DisplayPorts quantity	2
Mini HDMI ports quantity	0
HDMI version	2.1b
Mini DisplayPorts quantity	0
Thunderbolt 3 ports quantity	0
Performance
TV tuner integrated	No
DirectX version	12.0
OpenGL version	4.6
Dual Link DVI	No
Warranty period	3 year(s)
Overclocked (OC) edition	Yes
Design
Number of fans	3 fan(s)
Illumination colour	Multi
Illumination	Yes
Cooling type	Active
Form factor	Full-Height/Full-Length (FH/FL)
Product colour	Black
Cooling technology	GIGABYTE WINDFORCE 3X
Power
Minimum system power supply	450 W
Supplementary power connectors	1x 8-pin
Thermal Design Power (TDP)	151 W
Weight & dimensions
Weight	840 g
Height	118 mm
Depth	40 mm
Length	281 mm
Packaging data
Package type	Box
Package width	182.5 mm
Package depth	354 mm
Package height	75 mm
Package weight	1.29 kg
Technical details
Warranty period	3 year(s)
Logistics data
Products per shipping (inner) case	1 pc(s)
