Collection: Laptop Docks & Port Replicators

2 x DisplayPort, 1 x HDMI, 3 x USB 3.1, 2 x USB 2.0, 1 x USB Type C, 1 x Gigabit LAN, 90W

Description

The ThinkPad Universal USB-C Dock is a welcome innovation docking that takes users beyond tradition and into the realm of limitless potential. Experience universal compatibility with dynamic power charging max as 100w to notebooks, Automated firmware updates, Next-level plug-and-play. Everything you'd want from the future of docking is here. It's perfect for mixed PC environments too, giving user's the freedom to connect any USB Type C industray standard Notebooks.

One Dock. No Limits.
Engineered for performance, the ThinkPad Universal USB-C Dock quickly pays for itself with increased productivity, enhanced dynamic power charging to Notebook, max 100W charging. If you can think it, your dock can do it.

One Cable. No Hassle.
With 11+ thoughtfully placed ports, the ThinkPad Universal USB-C Dock delivers unmatched performance while decluttering your desk.

Entire Fleet. One Manager.
The ThinkPad Universal USB-C Dock comes packed with basic and advanced solutions engineered to make managing an entire fleet of docks effortlessly efficient. It could support tranditional IT tools like: PXE boot, WOL, and MAC address Pass Through on ThinkPad Notebooks, but also provide silent firmware updates. Silent reboots. Remote device queries. It's an IT manager's dream.

Specifications

Ports & interfaces
Combo headphone/mic port	Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	3
Connectivity technology	Wired
USB 2.0 ports quantity	2
Host interface	USB 3.2 Gen 1 (3.1 Gen 1) Type-C
Ethernet LAN (RJ-45) ports	1
HDMI ports quantity	1
DisplayPorts quantity	2
Microphone in	No
Network
Ethernet LAN	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s
Ethernet LAN (RJ-45) ports	1
Performance
Maximum digital resolution	3840 x 2160 pixels
Number of displays supported	3
Product colour	Black
On/off switch	Yes
Card reader integrated	No
Cable lock slot	Yes
Certification	FCC/ICES, KCC, RCM, BSMI, VCCI, CB, cULus, EAC, TUV- Mark, Kvalitet, LoA, Israel SII, DoC, NOM
Cable lock slot type	Kensington
HD type	4K Ultra HD
Storage
Card reader integrated	No
Power
Power source type	USB
Power connector	USB Type-C
Power supply	90 W
Software
Windows operating systems supported	Windows 10, Windows 7
Operational conditions
Operating temperature (T-T)	0 - 35 °C
Operating relative humidity (H-H)	20 - 95%
Weight & dimensions
Width	171 mm
Depth	80 mm
Height	30.8 mm
Weight	340 g
Package width	210 mm
Package depth	158 mm
Package height	75 mm
Package weight	955 g
Design
Windows operating systems supported	Windows 10, Windows 7
Product colour	Black
Cable lock slot	Yes
Certification	FCC/ICES, KCC, RCM, BSMI, VCCI, CB, cULus, EAC, TUV- Mark, Kvalitet, LoA, Israel SII, DoC, NOM
Cable lock slot type	Kensington
Packaging data
Quantity per pack	1 pc(s)
Package width	210 mm
Package depth	158 mm
Package height	75 mm
Package weight	955 g
Packaging content
Cables included	USB Type-C
Quantity per pack	1 pc(s)
Technical details
Compliance certificates	CE

Thunderbolt 4, 8K, 40Gbps

Description

Enterprise-Grade Universal Thunderbolt™ 4 Docking Experience: ThinkPad Universal Thunderbolt 4 Dock delivers reliable and consistent industry leading video, data and power connectivity in a Windows based mixed-PC environment. Maximize Your Productivity: Expand your horizon with versatile 8K display support or multiple 4K displays support, silent firmware upgrades, VPro/AMT support and transfer data at lightning fast 40Gbps. The ThinkPad Universal Thunderbolt 4 is future-proof and fully loaded to take your productivity, efficiency and creativity to the peak.

The ThinkPad Universal Thunderbolt™ 4 Dock supports upto 100W PD, Single 8K@30Hz or upto 4 4K@60HZ display support, silent firmware upgrades, vPro/AMT Pass through support, and data transfer rates upto 40 Gbps (depending on host system and peripheral processing capability, file attributes, and other configuration and operating environment factors)

Specifications

Ports & interfaces
Combo headphone/mic port	Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	1
Connectivity technology	Wired
Host interface	Thunderbolt 4
Ethernet LAN (RJ-45) ports	1
HDMI ports quantity	1
HDMI version	2.1
DisplayPorts quantity	2
Headphone connectivity	3.5 mm
DC-in jack	Yes
DisplayPort version	1.4
Thunderbolt 4 ports quantity	1
Network
Ethernet LAN	Yes
Ethernet LAN (RJ-45) ports	1
Performance
Product colour	Black
Certification	cULus, FCC, ICES, NOM
Power
Power source type	DC
Input current	6.75 A
Power consumption (max)	100 W
Power supply	135 W
Software
Windows operating systems supported	Yes
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95%
Weight & dimensions
Width	220 mm
Depth	80 mm
Height	30 mm
Weight	450 g
Package width	270 mm
Package depth	195 mm
Package height	85 mm
Package weight	1.2 kg
Design
Windows operating systems supported	Yes
Product colour	Black
Certification	cULus, FCC, ICES, NOM
Packaging data
Package width	270 mm
Package depth	195 mm
Package height	85 mm
Package weight	1.2 kg
Packaging content
AC adapter included	Yes

ThinkPad Hybrid USB-C with USB-A Dock

Description

The ThinkPad Hybrid USB-C with USB-A Dock expands the capabilities of most any laptop, new or old, making it perfect for enterprise customers with mixed-PC or shared-desk environments. It features enterprise-class manageability like PXE boot and MAC address pass-through. The ThinkPad Hybrid USB-C with USB-A Dock offers three high-speed USB 3.1 ports, up to dual UHD 4K resolution and rapid charging on ThinkPad notebooks. With the included USB-C to USB-A adaptor, it can also provide port replication to non-Lenovo or non-USB-C notebooks.

Specifications

Ports & interfaces
Combo headphone/mic port	Yes
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	3
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	1
Connectivity technology	Wired
USB 2.0 ports quantity	2
Host interface	USB 3.2 Gen 2 (3.1 Gen 2) Type-C
Ethernet LAN (RJ-45) ports	1
HDMI ports quantity	2
DisplayPorts quantity	2
Microphone in	Yes
Headphone outputs	1
Headphone connectivity	3.5 mm
DC-in jack	Yes
Network
Ethernet LAN	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s
Ethernet LAN (RJ-45) ports	1
Performance
Product colour	Black
Card reader integrated	No
Brand compatibility	Lenovo
Compatibility	E580, E480, E470, L580, L480, L470, L380, L380 Yoga, Lenovo Tablet 10, Miix 520-12IKB, T580, T570, T480, T480s, T470, T470s, T460, ThinkPad 25, X1 Carbon Gen 6, X1 Carbon Gen 5, X1 Yoga Gen 3, X1 Yoga Gen 2, X1 Tablet Gen 3, X1 Tablet Gen 2, 13 Gen 3 Windows, X280, X270, X260
Storage
Card reader integrated	No
Power
Power source type	DC
Power supply	135 W
Weight & dimensions
Width	210 mm
Depth	80 mm
Height	30 mm
Design
Product colour	Black
Packaging content
Cables included	USB
AC adapter included	Yes

USB 3.1 Type C (USB-C) to VGA + USB A + USB-C

Description

Astrotek Thunderbolt USB 3.1 Type C (USB-C) to VGA + USB + Card Reader Video Adapter Converter Male to Female for Apple Macbook Chromebook Pixel White

USB3.1 Type C to VGA+AF+C F, ABS ， white cover+green logo,C with gold plated,TPE white cable, same as sample,32/24AWG-TC，PE bag

The ASTROTEK USB-C to Ethernet Adapter is an ideal solution for wired network connectivity and data transfer on the go,reach 1000Mhz Gigabits, in the office, or any work space. This adapter connects to a USB-C or Thunderbolt 3 enabled laptop, tablet, or desktop computer and features an Ethernet port. This adapter converter is a perfect accessory for Apple, Microsoft Surface, and other leading laptops and tablets.

• Supports RJ45 Gigabit Ethernet
• Reversible USB-C connector
• Compatible with USB-C and Thunderbol 3 ports
• Plug and Play—no driver required

Specifications

Performance
Product colour	White
Plug and Play	Yes
Design
Product colour	White
Packaging data
Quantity per pack	1 pc(s)
Packaging content
Quantity per pack	1 pc(s)

USB-C Male to HDMI Female, USB-A Female, USB-C Female

Description

Astrotek USB 3.1 Type-C (USB-C) to HDMI, USB Type-A and USB Type-C Adapter Male to Female for Apple MacBook Chromebook Pixel

• Supports up to a 4K (4096 x 2160 at30Hz) resolution
• Reversible USB-C connector
• Compatible with USB-C and Thunderbol 3 ports
• Plug and Play—no driver required

Specifications

Performance
Product colour	White
Design
Product colour	White
Packaging data
Quantity per pack	1 pc(s)
Packaging content
Quantity per pack	1 pc(s)

USB 3.1 Type C to RJ-45 + 3 x USB 3.0 Hub

Description

Astrotek USB 3.1 Type C to LAN + USB3.0 Hub Gigabit RJ45 Ethernet Network Adapter Converter Cable 20cm

The ASTROTEK USB C Hubwith Networking Adapter for Macbook Pro, ChromeBook, simply expand 3 x USB3.0 super speed ports to your PC and enjoy faster data sync transfer rates up to 5Gbps, gigabit ethernet port enable you to access rapid data transfer and wired internet connectivity immediately

• USB 3.0 A ports support SuperSpeed (5 Gbps) data transmission
• RJ45 port supports 100/1000Mhz Ethernet
• Aluminum housing design

Specifications

Ports & interfaces
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
Connectivity technology	Wired
Host interface	USB 3.2 Gen 1 (3.1 Gen 1) Type-C
Ethernet LAN (RJ-45) ports	1
Microphone in	No
Network
Ethernet LAN	Yes
Ethernet LAN data rates	100,1000 Mbit/s
Ethernet LAN (RJ-45) ports	1
Performance
Product colour	White
Card reader integrated	No
Plug and Play	Yes
Storage
Card reader integrated	No
Power
Power source type	USB
USB cable length	0.2 m
Design
Product colour	White
Packaging data
Quantity per pack	1 pc(s)
Packaging content
Quantity per pack	1 pc(s)
