ASUS ROG Strix G16 G614PM-RV065W laptop AMD Ryzen™ 9 8940HX 40.6 cm (16") WUXGA 16 GB DDR5-SDRAM 1 TB SSD NVIDIA GeForce RTX 5060 Wi-Fi 6E (802.11ax) Windows 11 Home Black, Grey

AMD Ryzen 9 8940HX (2.4GHz), 16GB DDR5-SDRAM, 1000GB SSD, 40.6 cm (16") WUXGA 1920 x 1200 IPS-Level, AMD Radeon 610M, NVIDIA GeForce RTX 5060 (8GB GDDR7), LAN, WLAN, Webcam, Windows 11 Home 64-bit

Key Features

• Windows 11 Home 64-bit
• AMD Ryzen 9 8940HX (2.4GHz)
• 40.6 cm (16") WUXGA 1920 x 1200 IPS-Level, NVIDIA GeForce RTX 5060 (8GB GDDR7)
• 16GB (5200MHz) DDR5-SDRAM (2 x 8) & 1000GB SSD

Description

Power up your play
Draw more frames and win more games with the brand new Strix G16 and Windows 11 Pro. Powered by up to an AMD Ryzen™ 9 9955HX3D processor and up to an NVIDIA® GeForce RTX™ 5070 Ti Laptop GPU boasting a max TGP of 140W with Dynamic Boost, be ready to dominate the competition in all of the latest games. With up to 32GB of 5600MHz DDR5 RAM and PCIe Gen 4.0 SSD storage, and the ability to upgrade one slot to a PCIe Gen 5 drive*, large game libraries and intense multitasking sessions are a breeze for this gaming machine.

Specifications

Design
Colour name	Eclipse Gray
Product type	Laptop
Product colour	Black, Grey
Form factor	Clamshell
Market positioning	Gaming
Housing material	Plastic
Introduction year	2025
Display
HD type	WUXGA
Display diagonal	40.6 cm (16")
Display resolution	1920 x 1200 pixels
Touchscreen	No
Display brightness	300 cd/m²
Panel type	IPS-Level
Anti-glare screen	Yes
Maximum refresh rate	165 Hz
RGB colour space	sRGB
High Dynamic Range (HDR) technology	Dolby Vision
Colour gamut	100%
Native aspect ratio	16:10
High Dynamic Range (HDR) supported	Yes
Processor
Processor generation	AMD Ryzen 8000 Series
Processor cache type	L2 & L3
Processor frequency	2.4 GHz
Processor family	AMD Ryzen™ 9
Processor model	8940HX
Processor boost frequency	5.3 GHz
Processor cores	16
Processor threads	32
L3 cache	64 MB
L2 cache	16 MB
Processor manufacturer	AMD
Memory
Internal memory	16 GB
Internal memory type	DDR5-SDRAM
Memory clock speed	5200 MHz
Memory layout (slots x size)	2 x 8 GB
Memory slots	2x SO-DIMM
Maximum internal memory	64 GB
Memory form factor	SO-DIMM
Storage
SSD form factor	M.2
Optical drive type	No
Total storage capacity	1 TB
Storage media	SSD
Number of SSDs installed	1
SSD capacity	1 TB
SSD interface	PCI Express 4.0
Card reader integrated	No
Total SSDs capacity	1 TB
NVMe	Yes
Graphics
Discrete graphics card	Yes
NVIDIA G-SYNC	Yes
Discrete graphics card memory	8 GB
On-board graphics card family	AMD Radeon
On-board graphics card model	AMD Radeon 610M
Discrete graphics card model	NVIDIA GeForce RTX 5060
Discrete graphics memory type	GDDR7
On-board graphics card	Yes
Discrete GPU manufacturer	NVIDIA
On-board GPU manufacturer	AMD
Audio
Audio system	Smart Amp
Number of built-in speakers	2
Built-in microphone	Yes
Camera
Front camera	Yes
Front camera HD type	Full HD
Optical drive
Optical drive type	No
Network
Mobile network connection	No
Top Wi-Fi standard	Wi-Fi 6E (802.11ax)
Bluetooth	Yes
Wi-Fi standards	Wi-Fi 6E (802.11ax)
Ethernet LAN	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s
Bluetooth version	5.3
Antenna type	2x2
Ports & interfaces
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	2
USB Type-C DisplayPort Alternate Mode	Yes
USB 2.0 ports quantity	0
HDMI ports quantity	1
HDMI version	2.1
Ethernet LAN (RJ-45) ports	1
Combo headphone/mic port	Yes
USB Power Delivery (USB PD)	Yes
USB4 Gen 3x2 ports quantity	2
Power adapter barrel connector	6.0 mm
DC-in jack	Yes
Keyboard
Pointing device	Touchpad
Numeric keypad	No
Keyboard backlit	Yes
Keyboard backlit colour	RGB
Keyboard backlit zone	Per-key RGB
Software
Operating system installed	Windows 11 Home
Operating system architecture	64-bit
Battery
Battery technology	Lithium-Ion (Li-Ion)
Number of battery cells	4
Battery capacity	90 Wh
Fast charging	Yes
Fast charging time (50%)	30 min
Power
AC adapter power	280 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	14 A
AC adapter output voltage	20 V
USB Power Delivery (USB PD)	Yes
USB Type-C charging port	Yes
DC-in jack	Yes
Security
Trusted Platform Module (TPM)	Yes
Password protection	Yes
Password protection type	BIOS, User
Weight & dimensions
Weight	2.5 kg
Width	354 mm
Depth	264 mm
Height (front)	2.26 cm
Height (rear)	3.04 cm
Packaging data
AC adapter included	Yes
Packaging content
AC adapter included	Yes
Technical details
Discrete graphics card memory	8 GB
Other features
Audio system	Smart Amp
On-board graphics card	Yes
AC adapter included	Yes
Anti-glare screen	Yes
