ASUS NUC 15 Pro RNUC15CRHU500004I PC/workstation barebone Black 225H

ASUS NUC 15 Pro RNUC15CRHU500004I, Mini PC barebone, DDR5-SDRAM, M.2, Ethernet LAN, Wi-Fi 7 (802.11be)

Description

ASUS NUC 15 Pro RNUC15CRHU500004I. Product type: Mini PC barebone. Supported memory types: DDR5-SDRAM, Number of memory slots: 2, Maximum internal memory: 96 GB. Supported storage drive types: SSD, Storage drive interface: M.2. Ethernet LAN (RJ-45) ports: 1. Wi-Fi standards: Wi-Fi 7 (802.11be), Bluetooth version: 5.4

Specifications

Processor
Built-in processor	Yes
Processor model	225H
Processor boost frequency	4.9 GHz
Processor threads	14
Processor family	Intel Core Ultra 5
Processor cores	14
Processor manufacturer	Intel
Processor cache	18 MB
Performance cores	4
Efficient cores	8
Performance-core Max Turbo Frequency	4.9 GHz
Efficient-core Max Turbo Frequency	4.3 GHz
Performance-core base frequency	1.7 GHz
Efficient-core base frequency	1.3 GHz
Low Power Efficient-cores	2
Low Power Efficient-core Max Turbo Frequency	2.5 GHz
Low Power Efficient-core Base Frequency	700 MHz
Processor generation	Intel Core Ultra (Series 2)
Memory
Memory slots type	SO-DIMM
Number of memory slots	2
Supported memory types	DDR5-SDRAM
Supported memory clock speeds	6400 MHz
Memory channels	Dual-channel
Maximum internal memory	96 GB
Internal memory installed	No
Video
Graphics card family	Intel
On-board graphics card	Yes
Storage
Supported storage drive types	SSD
Storage drive sizes supported	M.2
Storage drive interface	M.2
SSD form factor	M.2
NVMe	Yes
Storage drives installed	No
Graphics
Graphics card family	Intel
On-board graphics card	Yes
On-board graphics card model	Intel Arc 130T
Audio
Built-in speaker(s)	No
Network
Wi-Fi standards	Wi-Fi 7 (802.11be)
Ethernet LAN	Yes
Wi-Fi	Yes
Bluetooth version	5.4
Bluetooth	Yes
Top Wi-Fi standard	Wi-Fi 7 (802.11be)
Ports & interfaces
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	3
VGA (D-Sub) ports quantity	0
USB 2.0 ports quantity	1
HDMI version	2.1
HDMI ports quantity	2
Ethernet LAN (RJ-45) ports	1
DC-in jack	Yes
Thunderbolt 4 ports quantity	2
USB4 Gen 2x2 ports quantity	1
Design
Product type	Mini PC barebone
On/off switch	Yes
Product colour	Black
Cable lock slot type	Kensington
Cable lock slot	Yes
Performance
Operating system installed	No
Processor special features
Low Power Efficient-cores	2
Low Power Efficient-core Max Turbo Frequency	2.5 GHz
Low Power Efficient-core Base Frequency	700 MHz
Colour
Product colour	Black
Technical details
Cable lock slot type	Kensington
Cable lock slot	Yes
Software
Operating system installed	No
Management features
On/off switch	Yes
Power
AC adapter output voltage	19 V
Power supply type	External AC adapter
Weight & dimensions
Width	117 mm
Depth	112 mm
Height	54 mm
Weight	600 g
