ATX 3.1 ready, native dual-color PCIe CEM 5.1 connector
Supports NVIDIA® GeForce RTX™ 40 / 50 series graphics cards
Fully modular design, flat cables
80 PLUS Gold certified for high efficiency
Active PFC design
Protection with OVP / OCP / OPP / OTP / SCP / UVP
135 mm fluid dynamic bearing fan
LLC half bridge topology with DC-to-DC module design
Description
ATX 3.1 Ready The gaming power supply can hold up to 2x total power excursion and 3x GPU power excursion, remaining stable when paired with high performing graphics cards.
THE POWER YOU HAVE The single rail supply of power can properly deliver the power you need. For high-performance graphics cards and CPUs, this power supply's CPU & PCIe connectors are more than plenty.
PROTECTION MECHANISMS To make sure the entire system can operate safely and stably at all times, the power supply comes with a number of protection mechanisms to give you the best peace of mind.
Specifications
Cooling
Fan diameter
13.5 cm
Number of fans
1 fan(s)
Fan speed
500 - 1800 RPM
Cooling type
Active
Performance
On/off switch
Yes
Power supply unit (PSU) form factor
ATX
80 PLUS certification
80 PLUS Gold
Purpose
PC
ATX version
3.1
Bearing technology
FDB
Design
80 PLUS certification
80 PLUS Gold
Product colour
White
Fan diameter
13.5 cm
Illumination
No
On/off switch
Yes
Number of fans
1 fan(s)
Fan speed
500 - 1800 RPM
Cooling type
Active
Power
Total power
1000 W
AC input voltage
100 - 240 V
AC input frequency
50/60 Hz
Power Factor Correction (PFC) type
Active
Combined power (+3.3V)
120 W
Combined power (+12V)
999.6 W
Combined power (+5V)
120 W
Combined power (-12V)
3.6 W
Combined power (+5Vsb)
15 W
Max output current (+3.3V)
22 A
Max output current (+12V)
83.3 A
Max output current (+5V)
22 A
Max output current (-12V)
0.3 A
Max output current (+5Vsb)
3 A
Power protection features
Over current, Over power, Over voltage, Overheating, Short circuit, Under voltage
