NZXT C1200 Gold power supply unit 1200 W 24-pin ATX ATX Black
NZXT C1200 Gold power supply unit 1200 W 24-pin ATX ATX Black
NZXT C1200 Gold power supply unit 1200 W 24-pin ATX ATX Black
NZXT C1200 Gold power supply unit 1200 W 24-pin ATX ATX Black
NZXT C1200 Gold power supply unit 1200 W 24-pin ATX ATX Black
NZXT C1200 Gold power supply unit 1200 W 24-pin ATX ATX Black

NZXT C1200 Gold power supply unit 1200 W 24-pin ATX ATX Black

NZXT C1200 Gold power supply unit 1200 W 24-pin ATX ATX Black

SKU: NZT-PA-2G1BB-AU

Availability: Sold out 10+ in stock
Regular price $285.56
Price: $285.56 Regular price $332.95
Taxes included.
ATX v3.0, 1200 W, 100 - 240Vac:14A-7A 50Hz-60Hz, Black

Key Features

  • 16-pin PCIe 12VHPWR connector can pump up to 600 watts of power to a graphics card over a single cable
  • Built and tested with the strictest standards for trouble-free installation and operation
  • 90.5% efficiency peak at 50% load lowers temperatures, energy consumption, and noise
  • Zero Fan Mode stops the fan when under light loads to reduce system noise
  • 135mm PWM fan with fluid dynamic bearing operates quietly with a long lifespan
  • Constructed with high-quality Japanese 105°C capacitors

Description

Utilizing the ATX v3.0 power standard, the NZXT C1200 Gold pumps up to 600 watts of power to NVIDIA 40-series graphics cards over a single cable while maintaining highly efficient, low-noise performance.

Specifications

Cooling
Fan diameter 13.5 cm
Fan speed 0 - 2300 RPM
Design
80 PLUS certification 80 PLUS Gold
Product colour Black
Fan diameter 13.5 cm
Fan speed 0 - 2300 RPM
Power
Total power 1200 W
AC input voltage 100 - 240 V
AC input frequency 50 - 60 Hz
Input current 7 - 14 A
Power Factor Correction (PFC) type Active
Combined power (+3.3V) 120 W
Combined power (+12V) 1200 W
Combined power (+5V) 15 W
Combined power (-12V) 3.6 W
Combined power (+5Vsb) 15 W
Max output current (+3.3V) 22 A
Max output current (+12V) 100 A
Max output current (-12V) 0.3 A
Ports & interfaces
SATA power cable length 150,500 mm
Peripheral (Molex) power cable length 150,500 mm
Motherboard power connector 24-pin ATX
Number of SATA power connectors 8
Peripheral (Molex) power connectors (4-pin) 4
PCI Express power connectors (6+2 pin) 2
CPU power connector (4+4 pin) Yes
ATX Power connector (24-pin) Yes
Cabling type Fully-Modular
Performance
Power supply unit (PSU) form factor ATX
80 PLUS certification 80 PLUS Gold
Purpose PC
ATX version 3.0
Bearing technology FDB
Mean time between failures (MTBF) 100000 h
Operational conditions
Operating temperature (T-T) 0 - 50 °C
Weight & dimensions
Width 150 mm
Depth 150 mm
Height 86 mm
Certificates
80 PLUS certification 80 PLUS Gold
