Yealink MCore Pro Intel® Core™ i5 i5-1145G7E 8 GB DDR4-SDRAM 128 GB SSD Windows 11 IoT Enterprise Mini PC Black

MCore Pro, i5-1145G7E, 8GB(2*4GB) DDR4, 128GB SSD, Bluetooth: BT 5.2

Key Features

• Intel Core 11th i5 processor
• 3 x HDMI out
• Support TPM 2.0
• Support vPro Platform*
• Support CEC
• Built-in security slot

Description

A mini-PC designed specifically for video conference room systems
Yealink MCore Pro is a Mini-PC specially designed for Yealink conference room systems. It uses the Intel Core 11th generation i5 processor with excellent performance, providing powerful data processing capabilities for conference room systems. MCore Pro has three built-in HDMI video output interfaces, which support the simultaneousdisplay of three screens to provide a diverse video conferencing experience. Use the TPM 2.0 with the Intel vPro Platform* to keep your data secure. The automatic wake-up screen feature supported by CEC allows you to enjoy the convenient experience by one touch. In addition, the built-in security slot of the MCore Pro can provide you with a simple and reliable deployment experience.

*vPro Platform is only supported when using Intel i5-1145G7E

Specifications

Processor
Processor generation	11th gen Intel® Core™ i5
Processor cache type	Smart Cache
Processor family	Intel® Core™ i5
Processor manufacturer	Intel
Processor model	i5-1145G7E
Processor cores	4
Processor boost frequency	4.1 GHz
Processor cache	8 MB
Processor threads	8
Memory
Internal memory	8 GB
Internal memory type	DDR4-SDRAM
Memory layout (slots x size)	2 x 4 GB
Storage
Total storage capacity	128 GB
Optical drive type	No
Storage media	SSD
Number of storage drives installed	1
Number of SSDs installed	1
SSD capacity	128 GB
Total SSDs capacity	128 GB
Graphics
Discrete graphics card	No
On-board graphics card family	Intel Iris Xe Graphics
Discrete graphics card model	Not available
On-board graphics card model	Intel Iris Xe Graphics
On-board graphics card	Yes
On-board GPU manufacturer	Intel
Optical drive
Optical drive type	No
Network
Ethernet LAN	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s
Wi-Fi	Yes
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6E (802.11ax)
Bluetooth	Yes
Bluetooth version	5.2
Top Wi-Fi standard	Wi-Fi 6E (802.11ax)
Ports & interfaces
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
HDMI ports quantity	3
Ethernet LAN (RJ-45) ports	1
DC-in jack	Yes
Design
Product colour	Black
Chassis type	Mini PC
Cable lock slot	Yes
Performance
Product type	Mini PC
Trusted Platform Module (TPM)	Yes
BIOS type	UEFI
Software
Operating system installed	Windows 11 IoT Enterprise
Power
Power supply input voltage	19 V
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 95%
Weight & dimensions
Width	168 mm
Depth	197 mm
Height	39 mm
Weight	690 g
Package width	203 mm
Package depth	265 mm
Package height	148 mm
Package weight	1.43 kg
Packaging data
Package width	203 mm
Package depth	265 mm
Package height	148 mm
Package weight	1.43 kg
Packaging content
Display included	No
Cables included	HDMI
Other features
Processor manufacturer	Intel
Trusted Platform Module (TPM)	Yes
On-board graphics card	Yes
