ASUS Zenbook S 14 OLED UX5406SA-PZ048W Copilot+ PC Intel Core Ultra 7 258V Laptop 35.6 cm (14") Touchscreen 3K 32 GB LPDDR5x-SDRAM 1 TB SSD Wi-Fi 7 (802.11be) Windows 11 Home Grey

Intel Core Ultra 7 258V (12MB Cache), 32GB LPDDR5x-SDRAM, 1000GB SSD, 35.6 cm (14") 3K 2880 x 1800 OLED Touch, Intel Arc Graphics 140V, WLAN, Webcam, Windows 11 Home 64-bit

Key Features

• Windows 11 Home 64-bit
• Intel Core Ultra 7 258V (12MB Cache)
• 35.6 cm (14") 3K 2880 x 1800 OLED Touch
• 32GB LPDDR5x-SDRAM & 1000GB SSD

Description

New Zen with superior AI
Experience the world-changing power of AI with Zenbook S 14, a new-era ASUS Copilot+ PC that combines an exceptional 1.1 cm-slim1 design with cutting-edge technology. Its all-metal body — with a unique Ceraluminum™ high-tech ceramic lid and nature-inspired colors — houses next-level AI capabilities, driven by up to the latest Intel® Core™ Ultra 9 processor (Series 2) with ambient cooling minimize noise. Immerse yourself in a visual feast with the stunning 3K ASUS Lumina OLED2 display, complemented by rich and powerful sound from the four-speaker audio system. Zenbook S 14 brings you elegance, power, and innovation in a slim and sophisticated package.

Specifications

Design
Colour name	Zumaia Gray
Product type	Laptop
Product colour	Grey
Form factor	Clamshell
Market positioning	Home
Housing material	Aluminium
Introduction year	2024
Display
HD type	3K
Display number of colours	1.073 billion colours
Display diagonal	35.6 cm (14")
Display resolution	2880 x 1800 pixels
Touchscreen	Yes
Display surface	Gloss
Display brightness	400 cd/m²
Display response rise/fall	0.2 ms
Panel type	OLED
Contrast ratio (typical)	1000000:1
Maximum refresh rate	120 Hz
RGB colour space	DCI-P3
High Dynamic Range (HDR) technology	HDR True Black 500
Colour gamut	100%
Native aspect ratio	16:10
High Dynamic Range (HDR) supported	Yes
Maximum display brightness (HDR)	500 cd/m²
Processor
Processor generation	Intel Core Ultra (Series 2)
Processor cache type	Smart Cache
Processor family	Intel Core Ultra 7
Processor model	258V
Processor boost frequency	4.8 GHz
Processor cores	8
Processor threads	8
Processor cache	12 MB
Processor manufacturer	Intel
Processor base power	17 W
Maximum turbo power	37 W
Performance-core base frequency	2.2 GHz
Performance-core Max Turbo Frequency	4.8 GHz
Performance cores	4
Low Power Efficient-core Base Frequency	2200 MHz
Low Power Efficient-core Max Turbo Frequency	3.7 GHz
Low Power Efficient-cores	4
Neural processor unit (NPU)
Neural processor unit (NPU)	Intel AI Boost
Sparsity support	Yes
Windows Studio effects support	Yes
AI software frameworks supported by NPU	DirectML, OpenVINO, Windows ML, ONNX RT, WebNN
Total processor performance up to	115 TOPs
NPU performance up to	47 TOPs
GPU performance up to	64 TOPs
Copilot+ PC	Yes
Memory
Internal memory	32 GB
Internal memory type	LPDDR5x-SDRAM
Maximum internal memory	32 GB
Memory form factor	On-board
Storage
SSD form factor	M.2
Optical drive type	No
Total storage capacity	1 TB
Storage media	SSD
Number of SSDs installed	1
SSD capacity	1 TB
SSD interface	PCI Express 4.0
Total SSDs capacity	1 TB
NVMe	Yes
Graphics
Discrete graphics card	No
On-board graphics card family	Intel Arc Graphics
On-board graphics card model	Intel Arc Graphics 140V
Discrete graphics card model	Not available
On-board graphics card	Yes
On-board GPU manufacturer	Intel
Audio
Audio system	Smart Amp
Built-in microphone	Yes
Camera
Front camera	Yes
Front camera resolution	1920 x 1080 pixels
Front camera HD type	Full HD
Infrared (IR) camera	Yes
Windows Hello	Yes
Optical drive
Optical drive type	No
Network
Mobile network connection	No
Top Wi-Fi standard	Wi-Fi 7 (802.11be)
Bluetooth	Yes
Wi-Fi standards	Wi-Fi 7 (802.11be)
Ethernet LAN	No
Bluetooth version	5.4
Antenna type	2x2
Ports & interfaces
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	1
USB Type-C DisplayPort Alternate Mode	Yes
USB 2.0 ports quantity	0
HDMI ports quantity	1
HDMI version	2.1
Combo headphone/mic port	Yes
USB Power Delivery (USB PD)	Yes
Thunderbolt 4 ports quantity	2
Intel® Thunderbolt 4	Yes
Performance
Repairability index	9.4
Keyboard
Pointing device	Touchpad
Numeric keypad	No
Keyboard backlit	Yes
Copilot key	Yes
Software
Operating system installed	Windows 11 Home
Operating system architecture	64-bit
Trial software	1-month trial for new Microsoft 365 customers
Microsoft Copilot	Yes
Copilot+ PC	Yes
Battery
Battery technology	Lithium-Ion (Li-Ion)
Number of battery cells	4
Battery capacity	72 Wh
Power
AC adapter power	65 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	3.25 A
AC adapter output voltage	20 V
USB Power Delivery (USB PD)	Yes
USB Type-C charging port	Yes
Security
Trusted Platform Module (TPM)	Yes
Password protection	Yes
Face recognition	Yes
Windows Hello	Yes
Certificates
Compliance certificates	REACH
Sustainability
Sustainability certificates	ENERGY STAR
Weight & dimensions
Weight	1.2 kg
Width	310.3 mm
Depth	214.7 mm
Height (front)	1.19 cm
Height (rear)	1.29 cm
Packaging data
AC adapter included	Yes
Packaging content
AC adapter included	Yes
Technical details
Sustainability certificates	ENERGY STAR
Repairability index	9.4
Compliance certificates	REACH
Other features
Audio system	Smart Amp
On-board graphics card	Yes
AC adapter included	Yes
